Каталог запасных частей к технике: Gaspardo Сеялка MAXIMETRO. PRESS WHEEL
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
14
15
16
17
18
19
20
21
22
23
23
24
25
25
26
27
28
28
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | G17720221 | Rear lever assembly | |
| 2 | G17720363 | Compression wheel support | |
| 3 | G18801480 | Bushing | |
| 4 | G18904560 | Spring | |
| 5 | G17722340 | Spring connection zn | |
| 6 | F01020088 | SCREW M8X1,25X90 U5737 8.8 ZN | |
| 7 | F01020445 | BOLT M8X30 | |
| 8 | F01220022 | NUT M8X1,25 D980 8 ZN | |
| 9 | F01020539 | Bolt | |
| 10 | F01230073 | Self locking nut | |
| 11 | F01020156 | SCREW M12X1,75X50 U5737 8.8 ZN | |
| 12 | F01230059 | Nut | |
| 13 | F01020266 | Bolt | |
| 14 | G18803240 | Bushing | |
| 15 | F01230085 | Nut | |
| 16 | F01410100 | Plane washer | |
| 17 | G18803081 | Bushing | |
| 18 | F01020174 | Bolt | |
| 19 | G17722452 | Eccentric bushing zn | |
| 20 | F06120292 | Rubber wheel | |
| 21 | F01230034 | SELF LOCK.NUT M8X1,25 D982 8ZN | |
| 22 | G19007120 | Wheel cover | |
| 23 | F01410051 | WASHER M8 8,4X17X1,6 U6592 ZN | |
| 24 | F01020068 | SCREW M8X1,25X40 U5737 8.8 ZN | |
| 25 | F04100154 | Bearing | |
| 26 | G17722630 | Wheelcast iron | |
| 27 | G17722930 | Cast iron wheel el.regina | |
| 28 | G17740850 | Flange |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
