Каталог запасных частей к технике: Gaspardo ROMINA. REAR COVER WHEELS
1
2
3
4
5
6
7
7
8
9
10
11
11
12
12
13
14
15
16
17
18
19
19
19
20
20
21
22
22
23
24
25
26
26
27
27
28
29
30
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | F01220022 | NUT M8X1,25 D980 8 ZN | |
| 2 | GA5220401 | Tail | |
| 3 | GA5220420 | Handle tail | |
| 4 | G17722340 | Spring connection zn | |
| 5 | G18904560 | Spring | |
| 6 | F01020068 | SCREW M8X1,25X40 U5737 8.8 ZN | |
| 7 | GA5220411 | Bushing | |
| 8 | G18803081 | Bushing | |
| 9 | F01020174 | Bolt | |
| 10 | F01230085 | Nut | |
| 11 | F01020152 | Bolt | |
| 12 | F01230059 | Nut | |
| 13 | F01020266 | Bolt | |
| 14 | G20980004 | Bushing | |
| 15 | G20980014 | Bushing | |
| 16 | G20970025 | WASHER 25-2X2X16-5 | |
| 17 | F06120412 | Rubb.wheel | |
| 18 | F06120181 | RUBBER RING 1X12' | |
| 19 | F04100150 | BEARING D16 D40 B39 WPC | |
| 20 | F01440086 | Washer | |
| 21 | F06120474 | F06120474 | |
| 22 | F06120165 | RUBBER RING 2X13' | |
| 23 | F06120408 | Rubber wheel | |
| 24 | G15224790 | COMPL. REAR CAST IRON WHEEL | |
| 25 | G15224800 | REAR WHEEL | |
| 26 | G16242190 | BEARING SUPPORT | |
| 27 | F04010156 | BEARING D20 D47 B14 6204 2RSH | |
| 28 | G15224810 | BUSH 20.5X25X3 | |
| 29 | G15423850 | STEEL WHEEL BUSH | |
| 30 | F01040091 | SCREW 8X20 5931 8.G ZN | |
| 31 | F01220022 | NUT M8X1,25 D980 8 ZN |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
