Каталог запасных частей к технике: Gaspardo METRO MT-SP. "SP" COMPRESSION WHEELS
1
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
19
19
20
21
21
22
23
24
25
26
27
28
29
30
30
31
31
32
33
34
35
35
36
37
38
39
40
40
41
41
42
43
44
45
46
47
48
49
49
50
50
51
52
52
52
52
53
54
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | F06120146 | PLASTIC HALF RIM1' WHEEL | |
| 2 | F06120165 | RUBBER RING 2X13' | |
| 3 | G15420913 | V-wheel support | |
| 4 | F01020481 | BOLT 10X40 5739 8.G GALVANIZED | |
| 5 | G22270235 | ADJUSTMENT HANDLE B4 | |
| 6 | F02100109 | PIN EL. .6X24 DIN 1481 | |
| 7 | G65336100 | Spec spring handle stop sp | |
| 8 | F06120155 | Tyre farmf. | |
| 9 | F06120022 | Wheel rim farmf. | |
| 10 | F01410088 | WAS.M14 15X28X2,5 U6592 ZB | |
| 11 | G16620430 | Wheel support | |
| 12 | F06220013 | 8-lobe handwheel | |
| 13 | G14820991 | Adjustment stop | |
| 14 | F01200270 | NUT M10X1,5 U5588 6.8 ZN | |
| 15 | G22220073 | Washer | |
| 16 | G22230062 | Adjustment bolt | |
| 17 | G22230063 | ARTICULATED ELEMENT | |
| 18 | F01020476 | SCREW M10X1,5X30 5739 8.8 ZN | |
| 19 | F01220022 | NUT M8X1,25 D980 8 ZN | |
| 20 | G15423460 | Soil scraper seed cov.linkage | |
| 21 | F01020449 | BOLT M8X35 | |
| 22 | G65337028 | Traction spring zn wheel supp. | |
| 23 | F06120181 | RUBBER RING 1X12' | |
| 24 | G15423840 | Wheel adjustment | |
| 25 | F02200227 | SPLIT PIN 5X30 1336 GALVAN. | |
| 26 | F06120147 | PLASTIC HALF RIM2' WHEEL | |
| 27 | F06120075 | RUBBER WHEEL 2'X13' PLA.2 BEAR | |
| 28 | F06120076 | RUBBER WHEEL 1'X12' PLA.2 BEAR | |
| 29 | G15423860 | Rear wheel assy | |
| 30 | G16242190 | BEARING SUPPORT | |
| 31 | F04010165 | Bearing | |
| 32 | G14820871 | Rear iron wheel | |
| 33 | G15423850 | STEEL WHEEL BUSH | |
| 34 | F01020128 | Screw | |
| 35 | F01420060 | WASHER 10,5X30 | |
| 36 | G10120621 | Left seed cover | |
| 37 | F01040091 | SCREW 8X20 5931 8.G ZN | |
| 38 | G18902910 | RIGHT SEED COVER SPRING SP | |
| 39 | G15422500 | Seed cover spring support bush | |
| 40 | F01420048 | WASHER M8 8,4X24X2 U6593 ZN | |
| 41 | G18701140 | WASHER 11X35X5 | |
| 42 | G18902920 | LEFT SEED COVER SPRING SP | |
| 43 | G10120611 | Right seed cover | |
| 44 | F01220033 | NUT M10X1,5 D980 8 ZN | |
| 45 | G14821590 | FARMFLEXWHEEL 370X165 DEPTH.A | |
| 46 | G15422481 | Right v wheel soil scraper | |
| 47 | G18902930 | Soil scraper hook | |
| 48 | G15422491 | Left v wheel soil scraper | |
| 49 | F01410037 | PLANE WASHER D.6 | |
| 50 | F01230022 | NORM.SELF-LOCKING NUT 6 GALVAN | |
| 51 | F01020042 | BOL.M6X1X50 U5737 8.8 ZG | |
| 52 | F04010131 | BEARING 6004 2RS EX. SKF | |
| 53 | G15226610 | GASKET SET FOR WHEEL V1 | |
| 54 | G15226620 | SEAL&SPACER-KIT FOR WHEEL V2 | |
| 55 | F01020406 | BOLT M6X25 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
