Каталог запасных частей к технике: Gaspardo ARTIGLIO. STILL MOD. 2003-2004-2005-2006-2007
/3.gif)
1
1
1
1
2
3
3
4
4
5
5
5
6
7
7
8
8
8
8
9
9
9
9
10
10
10
10
11
11
12
12
13
13
14
15
15
15
15
16
16
16
16
16
16
17
17
17
17
18
18
18
18
19
20
20
21
22
22
22
23
23
24
24
25
25
26
27
27
28
29
30
30
31
31
32
32
33
33
34
34
34
34
35
35
35
35
36
36
37
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | R17820012 | Support for earth-opening blad | |
| 2 | R17820191 | Tip | |
| 3 | G67002037 | Tip tooth | |
| 4 | F01220048 | NUT M12X1,75 D980 8 ZN | |
| 5 | F01061000 | Screw | |
| 6 | F20120103 | Hoe blade right | |
| 7 | F01030118 | Screw | |
| 8 | F01020269 | Bolt | |
| 9 | F01020344 | Screw | |
| 10 | F01200321 | Nut | |
| 11 | F01230059 | Nut | |
| 12 | F01230143 | NUT M24X2 D982 8 ZN | |
| 13 | F01200377 | Nut | |
| 14 | R17820240 | Clod-breaking | |
| 15 | F01020077 | SCREW M8X1,25X60 U5737 8.8 ZN | |
| 16 | F01220022 | NUT M8X1,25 D980 8 ZN | |
| 17 | F01230150 | Self-locking nut | |
| 18 | G18701590 | Washer | |
| 19 | F20120104 | Hoe blade left | |
| 20 | F01030107 | Bolt | |
| 21 | R17820192 | Tip | |
| 22 | R17820060 | Clod-breaking blade | |
| 23 | M01110427 | Left helicoidal blade | |
| 24 | M01110426 | Right helicoidal blade | |
| 25 | F01020207 | Bolt | |
| 26 | F01200093 | Nut | |
| 27 | R17820440 | Tip | |
| 28 | R17820480 | Tooth artig.quick fit | |
| 29 | R17820890 | Left helicoidal blade | |
| 30 | F01200379 | Nut | |
| 31 | F01230144 | Self-locking nut | |
| 32 | F01230073 | Self locking nut | |
| 33 | F01020082 | Bolt | |
| 34 | F01020164 | Bolt | |
| 35 | F01230059 | Nut | |
| 36 | R17820260 | Support blade | |
| 37 | G68020130 | Toothartig.tungsten revers. | |
| 38 | R17820630 | Tooth artig tungsten quick fit | |
| 39 | M66100425 | Right helicoidal blade tungst | |
| 40 | M66100426 | Left helicoidal blade tungsten | |
| 41 | R17820660 | Point artiglio rapido reversib | |
| 42 | R17820880 | Right helicoidal blade | |
| 43 | R17820850 | Right helicoidal blade | |
| 44 | R17820840 | Left helicoidal blade | |
| 45 | F01060600 | Bolt | |
| 46 | F01020210 | Bolt | |
| 47 | F01260047 | Nut | |
| 48 | R17820720 | Tooth art.tungsten quick f.rev | |
| 49 | F01020350 | Bolt | |
| 50 | R17821070 | Busching | |
| 51 | R17820860 | Right helicoidal blade | |
| 52 | R17820870 | Left helicoidal blade tungsten | |
| 53 | R17820830 | Right helicoidal blade | |
| 54 | R17820820 | Right helicoidal blade |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
