Каталог запасных частей к технике: Gaspardo ALITALIA. FOOTBOARD AND LADDER
1
2
3
4
5
6
7
7
7
8
8
8
9
9
9
9
9
9
9
9
9
9
10
10
10
10
10
10
10
10
10
10
10
11
12
13
13
14
14
15
16
16
17
17
17
17
18
19
20
21
22
23
24
25
25
26
27
27
28
29
30
30
30
30
30
30
30
30
30
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | G17210740 | LEFT SEEDCOVER HARROW SUPP. | |
| 2 | G17210730 | RIGHT SEEDCOVER HARROW SUPP. | |
| 3 | G17210661 | FOOTBOARD CENTRAL SUPP. | |
| 4 | G16310500 | PLATAFORM MC250 | |
| 5 | F01220048 | NUT M12X1,75 D980 8 ZN | |
| 6 | F01020510 | BOLT M12X30 | |
| 7 | F01020198 | Screw | |
| 8 | F01230073 | Self locking nut | |
| 9 | F01020436 | SCREW M8X1,25X20 U5739 8.8 ZN | |
| 10 | F01260043 | FLANGE NUT M8 DIN 6923 8.8 GAL | |
| 11 | F01020077 | SCREW M8X1,25X60 U5737 8.8 ZN | |
| 12 | F20110855 | Cav.t. | |
| 13 | F01220033 | NUT M10X1,5 D980 8 ZN | |
| 14 | F01410088 | WAS.M14 15X28X2,5 U6592 ZB | |
| 15 | G16314500 | R.UPPER STAIR SUPPORT | |
| 16 | G16314480 | BOARD SUPPORT | |
| 17 | G16310681 | GALVANIZED PLATFORM END | |
| 18 | G17917220 | Board | |
| 19 | G16013431 | PLATFORM 400X360X2 ZN | |
| 20 | G16314560 | HANDRAIL TUBEDAMA | |
| 21 | G67008050 | Round end | |
| 22 | G17211000 | SUPP.BRACKET CENTRAL FOOT. | |
| 23 | F20110770 | FLANGE U M14X2X50 96X119 ZN | |
| 24 | F01220255 | Nut-tristop | |
| 25 | G16242471 | STEP SUPPORT | |
| 26 | F20110715 | Striker | |
| 27 | G16072280 | PIPE GUIDE SUPPORT | |
| 28 | F01020125 | Screw | |
| 29 | F01230048 | Nut | |
| 30 | F01410051 | WASHER M8 8,4X17X1,6 U6592 ZN |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
