Каталог запасных частей к технике: Foton Europard 40. Front Driving Axle Assembly(qingjiang)
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | GB/T5783 | Болт M12x35 | |
| 2 | GB/T93 | Шайба 12 | |
| 3 | FT304.31.123 | Housing of bearing | |
| 4 | FT304.31.124 | Adjusting shim | |
| 5 | GB3452.1 | O-seal ring | |
| 6 | GB/T297-1994 | Bearing 30211 (2007113) | |
| 7 | FT304.31.125 | Small driven bevel gear | |
| 8 | FT304.31.127 | Spacer sleeve | |
| 9 | FT304.31.160 | Housing for right main pin | |
| 10 | FT304.31.134 | Adjusting shim | |
| 11 | FT304.31.145 | Washer | |
| 12 | QC/T379-1999 | Square head tapered plug M10x1 | |
| 13 | FT304.31.161 | Terminal housing,right | |
| 14 | FT304.31.119 | Stop washer | |
| 15 | FT304.31.118 | Circlip | |
| 16 | GB/T276-1994 | Deep groove ball bearing 6206 | |
| 17 | FT304.31.120 | Large conical gear of terminal transmission | |
| 18 | GB/T893.1-1986 | Упор - щит 42 | |
| 19 | GB/T276-1994 | Deep groove ball bearing 6206 | |
| 20 | GB/T9877.1-1998 | Oil sealing | |
| 21 | GB3452.1 | O-seal ring | |
| 22 | FT304.31.117 | Housing of bearing | |
| 23 | GB/T93 | Шайба 12 | |
| 24 | GB/T5783 | Болт M12x35 | |
| 25 | FT304.31.114 | Clothing | |
| 26 | GB3452.1 | O-seal ring | |
| 27 | FT304.31.116 | Dust cap | |
| 28 | FT304.31.113 | Bolt | |
| 29 | FT304.31.115 | Front driving shaft | |
| 30 | FT304.31.112 | Nut | |
| 31 | JB/T7940.1-1995 | Oil cup | |
| 32 | GB/T5783 | Болт M12x35 | |
| 33 | FT304.31.110 | Terminal cover | |
| 34 | FT304.31.130 | Adjusting shim | |
| 35 | GB/T297-1994 | Bearing 30211 (2007113) | |
| 36 | FT304.31.131 | Small terminal driving conical gear | |
| 37 | FT304.31.129 | Main shaft pin | |
| 38 | GB/T894.1-1986 | Circlip for shaft 55-Type A | |
| 39 | GB/T276-1994 | Deep groove ball bearing 6206 | |
| 40 | GB/T9877.1-1998 | Oil sealing | |
| 41 | FT304.31.133 | Dust ring | |
| 42 | FT304.31.132 | Sleeve |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
