Каталог запасных частей к технике: Foton Europard 40. Front Driving Axle Assembly(qingjiang)
1
1
2
3
4
4
5
5
6
6
7
7
8
9
10
11
12
13
14
14
15
16
17
18
19
20
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | GB/T297-1994 | Bearing 30211 (2007113) | |
| 2 | FT304.31.172 | Large bevel gear of central transmission | |
| 3 | FT304.31.171 | Sleeve of half axle gear | |
| 4 | FT304.177 | Washer of half axle gear | |
| 5 | FT304.31.176 | Half axle gear | |
| 6 | FT304.31.174 | Washer for planetary gear | |
| 7 | FT304.31.173 | Planetar gear | |
| 8 | FT304.31.178 | Housing of differential | |
| 9 | GB/T5782 | Болт M12x50 | |
| 10 | FT304.31.175 | Lock plate | |
| 11 | GB/T879-1986 | Pin | |
| 12 | FT304.31.179 | Shaft of planetary gear | |
| 13 | FT304.31.144 | Set screw | |
| 14 | GB/T93 | Шайба 12 | |
| 15 | FT304.31.142 | Case cover of central transmission | |
| 16 | GB/T5783 | Болт M12x35 | |
| 17 | GB/T72-1988 | Slotted set screw with cone point M8x20 | |
| 18 | FT304.31.140 | Housing of main reduction gear box | |
| 19 | DC/T379-1999 | Square head tapered plug M10x1 | |
| 20 | FT304.31.145 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
