Каталог запасных частей к технике: Foton Europard 40. Front Axle Assembly
1
1
2
2
3
3
4
4
5
6
6
7
7
7
7
8
8
8
8
9
9
9
9
10
10
10
10
11
11
12
13
13
13
13
14
14
14
14
15
15
15
15
16
16
17
17
18
18
19
20
21
21
22
22
23
24
24
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | GB/T5785 | Болт М20х1.5x125 | |
| 2 | FT400.31.137 | Cross drawbar clip | |
| 3 | GB/T97.1 | Шайба 12 | |
| 4 | GB/T6171 | Гайка М20х1.5 | |
| 5 | FT400.31.122 | Inner connecting pipe of cross drawbar,right | |
| 6 | GB/T6173 | Nut | |
| 7 | FT400.31.131 | Base plate | |
| 8 | FT400.31.132 | Ball bowl | |
| 9 | GB/T91 | Шплинт 3.2x25 | |
| 10 | FT400.31.139 | Ball pin | |
| 11 | FT400.31.133 | Right joint | |
| 12 | FT400.31.118 | Steering arm,right | |
| 13 | FT400.31.134 | Dust cap of joint | |
| 14 | FT400.31.130 | Keeper of dust cap | |
| 15 | GB/T9457 | Hexagon slotted and castele nut,-Fine pitch thread M14x1.5-Zn.D | |
| 16 | GB/T6170 | Гайка М6 | |
| 17 | GB/T93 | Шайба 12 | |
| 18 | GB/T5782 | Болт M12x50 | |
| 19 | FT400.31.120 | Cross drawbar | |
| 20 | FT400.31.121 | Inner connecting pipe of cross drawbar,left | |
| 21 | FT400.31.138 | Hexagon thin out,-Fine pitch thread M18x1.5LH-Zn.D | |
| 22 | FT400.31.129 | Left joint | |
| 23 | FT400.31.117 | Steering arm,left | |
| 24 | FT400.31.107 | Longitudinal drawbar | |
| 24 | FT300.31.107 | Longitudinal drawbar |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
