Каталог запасных частей к технике: Foton Europard 25. Front driving axle assembly-4
1
1
2
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| FT254.31F.001 | FT254.31F.001 | front driving axle assembly | |
| 1 | GB/T5783 | Болт M12x35 | |
| 2 | GB/T93 | Шайба 12 | |
| 3 | JB/T7940.1 | Масленка M10x1 | |
| 4 | GB/T6171 | Гайка М20х1.5 | |
| 5 | FT254.31F.154 | left steering rocker arm | |
| 6 | FT254.31F.107 | adjusting shim | |
| 7 | FT254.31F.104 | sliding bearing sleeve35x39x30 | |
| 8 | GB3452.1 | O-seal ring | |
| 9 | FT254.31F.105 | bearing cover seat | |
| 10 | FT254.31F.102 | sealing shim | |
| 11 | GB/T96 | Шайба 12 | |
| 12 | FT254.31F.106 | washer | |
| 13 | GB/T276 | Подшипник 212 | |
| 14 | FT254.31F.108 | great gear of half shaft | |
| 15 | FT254.31F.119 | vertical shaft | |
| 16 | FT254.31F.121 | steering knuckle case | |
| 17 | FT254.31F.113 | dust cover | |
| 18 | JB/T9877.1 | oil cover B507210D | |
| 19 | FT254.31F.122 | sliding bearing sleeve50x55x35 | |
| 20 | GB/T301 | Thrust ball bearing51106 | |
| 21 | FT254.31F.155 | end housing,right | |
| 22 | FT254.31F.118 | small end gear | |
| 23 | GB/T276 | Подшипник 212 | |
| 24 | FT254.31F.117 | adjusting shim | |
| 25 | Q/YXF70 | screw with square headNPT1/8-27 | |
| 26 | FT254.31F.116 | end cover | |
| 27 | GB/T899 | Doube end stud AM12-M12x1.25x50-8.8-A2L | |
| 28 | GB/T119 | Straight pin B12x24 | |
| 29 | GB/T93 | Шайба 12 | |
| 30 | GB/T5783 | Болт M12x35 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
