Каталог запасных частей к технике: CASE IH Axial Flow 2388. SEAT, OPERATOR - SUSPENSION

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
3
4
5
6
7
8
9
10
11
11A
12
13
13A
14
15
16
17
18
19
19
20
20
21
21
21A
21A
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
40
41
42
43
44
45
46
47
47
48
48
49
49
51
52
53
54
55
56
57
58
58
59
60
61
63
63
64
65
66
66
67
67
68
Позиция на иллюстрации Заводской номер детали Название детали
86989910 86989910 SEAT
1990647C2 1990647C2 KIT
1 Boot Boot
132872A1 132872A1 KIT
2 Fastener Fastener
3 Nut Nut
4 Clip Clip
87416447 87416447 KIT
5 180591A1 PLATE
6 180592A1 SHOCK ABSORBER
7 276-24812 SCREW
8 1990643C1 FRAME ASSY
9 A49529 SHAFT
10 231-4206 NUT
11 226560A1 HOUSING
11A A45054 BUMPER
12 443-13812 SCREW
197793A1 197793A1 SPRING
13 Spring Spring
13A Clamp Clamp
14 413-68 BOLT
15 131-425 NUT
180593A1 180593A1 KIT
16 Bumper Bumper
17 231-1444 NUT
18 340-12520 SCREW
180594A3 180594A3 KIT
19 Bushing Bushing
20 Roller Roller
21 Roller Roller
21A Roller Roller
22 131-425 NUT
23 Bearing Bearing
24 Bearing Bearing
25 Bearing Bearing
26 Bearing Bearing
27 Spacer Spacer
1344250C2 1344250C2 KIT
28 ShockAbsorber Shock Absorber
29 Bearing Bearing
30 A45519 WASHER
31 131-425 NUT
32 Bearing Bearing
227546A1 227546A1 KIT
33 ShockAbsorber Shock Absorber
34 434-48 BOLT
35 231-1444 NUT
36 495-11041 WASHER
37 Washer Washer
38 Spacer Spacer
39 230-4715 NUT
40 A49679 BUSHING
41 Bearing Bearing
42 1981845C1 ANGLE
1981852C3 1981852C3 SWITCH
43 Switch Switch
44 Nut Nut
45 493-11065 WASHER
46 1987186C2 KNOB
1990548C4 1990548C4 KIT
47 Elbow Elbow
48 Tube Tube
49 Tube Tube
51 L18337 STRAP
52 Clamp Clamp
53 179026A1 TUBE
54 133422A1 BUMPER
55 180596A2 LEVER
56 180597A2 HANDLE
358903A2 358903A2 KIT
57 Compressor Compressor
58 87413247 HARNESS
59 495-31022 WASHER
60 440-1086 SCREW
61 L18337 STRAP
291280A1 291280A1 KIT
63 Strap Strap
64 Screw Screw
65 Screw Screw
66 Washer Washer
67 Washer Washer
68 Strap Strap
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
