Каталог запасных частей к технике: AGCO Fendt-6300C часть1. Fuel Tank, Up To 563010119 /Autolevel 563410050
1
2
2
3
3
3
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
16
17
17
18
19
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
33
34
35
36
36
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LA5150924 | UNION | |
| 2 | LA10184314 | BANJO BOLT | |
| 3 | LA350391506 | CLIP | |
| 4 | LA10902224 | SCREW | |
| 5 | LA11106221 | SCREW | |
| 6 | LA11106624 | CAPSCREW | |
| 7 | LA11422324 | CAPSCREW | |
| 8 | LA12034671 | WASHER | |
| 9 | LA12035670 | WASHER | |
| 10 | LA12577211 | NUT | |
| 11 | LA14462880 | GASKET | |
| 12 | LA15214821 | SCREW | |
| 13 | LA15896221 | NUT | |
| 14 | LA16043824 | CAPSCREW | |
| 15 | LA16104111 | NUT | |
| 16 | LA322894550 | UNION | |
| 17 | LA322139100 | TANK | |
| 17 | LA323194700 | TANK | |
| 18 | LA322140950 | BAND | |
| 19 | LA322154150 | CONNECTOR | |
| 20 | LA322157450 | GASKET | |
| 21 | LA322165550 | PLUG | |
| 22 | LA322165650 | FUEL FILTER | |
| 23 | LA322223650 | CONNECTOR | |
| 24 | LA322325850 | WASHER | |
| 25 | LA322892950 | HOSE FLEXIBLE | |
| 26 | LA322893050 | HOSE | |
| 27 | LA322893150 | HOSE FLEXIBLE | |
| 28 | LA322894700 | CONNECTOR | |
| 29 | LA323091150 | STRAP | |
| 30 | LA323128100 | FILTER | |
| 31 | LA323152050 | FUEL FILTER | |
| 32 | LA340481810 | CABLE TIE | |
| 33 | LA350358742 | GASKET | |
| 34 | LA355500720 | WASHER | |
| 35 | LA355510820 | WASHER | |
| 36 | LA355511030 | WASHER |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
