Каталог запасных частей к технике: AGCO Fendt-524 (Xylon) часть1. FRONT P.T.O.
1
2
3
5
6
7
7
7
8
11
12
13
15
16
17
18
20
22
23
24
24
26
27
28
29
30
32
33
34
35
35
36
38
38
39
40
44
45
46
47
48
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Х550035100000 | ROTARY SHAFT SEAL | |
| 2 | Х605510600000 | GROOVE BALLBEARING | |
| 3 | Х550052602000 | ROTARY SHAFT SEAL | |
| 5 | 278116200140 | SCREENING SHEET | |
| 6 | Х530005246000 | CIRCLIP | |
| 7 | 015819190050 | SHIM | |
| 7 | 015819190051 | SHIM | |
| 7 | 015819190052 | SHIM | |
| 8 | Х623138820000 | BEVEL ROLLER BEARING | |
| 11 | Х622391000000 | PARALLEL ROLLERBEAR. | |
| 12 | Х530108846000 | CIRCLIP | |
| 13 | Х550115901000 | ROTARY SHAFT SEAL | |
| 15 | 339150200050 | CLUTCH SHAFT | |
| 16 | 205100200500 | OUTER CLUTCH DISC | |
| 17 | 395100201410 | INTERNAL CLUTCH DISC | |
| 18 | 395100201400 | INNER DISC | |
| 20 | 312100200060 | CLUTCH BELL | |
| 22 | Х533819246000 | SNAP RING | |
| 23 | Н312100200110 | GROOVE BALLBEARING | |
| 24 | Х530005446000 | CIRCLIP | |
| 26 | 514100200020 | PISTON | |
| 27 | Х540422300000 | SCRAPER | |
| 28 | Х547532800000 | GASKET | |
| 29 | Х560234800000 | GUIDE RING | |
| 30 | Х547532300000 | GASKET | |
| 32 | 312100200050 | BUSH | |
| 33 | Х530106546000 | CIRCLIP | |
| 34 | 312100200090 | DISC SPRING | |
| 35 | Х530107446000 | CIRCLIP | |
| 36 | Х534538846000 | SUPPORT DISC | |
| 38 | Х530005246000 | CIRCLIP | |
| 39 | Н312100200100 | GROOVE BALLBEARING | |
| 40 | 312100200021 | SHAFT | |
| 44 | Х606111111000 | GROOVE BALLBEARING | |
| 45 | Х605511211000 | GROOVE BALLBEARING | |
| 46 | Х550081705000 | ROTARY SHAFT SEAL | |
| 47 | 178100200190 | PTO SHAFT | |
| 48 | 380117221150 | PTO GUARD |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
