Каталог запасных частей к технике: Tata Telcoline-207. REAR WHEEL BRAKE (BRAKES INDIA)
2
2
4
4
7
8
9
10
10
11
13
14
14
14
14
14
15
15
15
15
15
17
17
18
19
20
21
22
23
23
24
25
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| Grease Tube | Grease Tube | Grease Tube | |
| Dust Cover | Dust Cover | Dust Cover | |
| Seal | Seal | Seal | |
| 2654 4230 01 17 | 2654 4230 01 17 | Minor Repair Kit (Wheel Cyl.) Consists of : | |
| 2699 4230 37 02 | 2699 4230 37 02 | Brake Drum Rear | |
| 2 | 2699 4230 01 04 | Assy. Rear Brake RH (Non Asbestos) | |
| 2 | 2699 4230 01 03 | Assy. Rear Brake LH (Non Asbestos) | |
| 4 | 2654 4230 82 01 | Anchor Plate LH | |
| 4 | 2654 4230 82 02 | Anchor Plate RH | |
| 7 | 2654 4230 87 01 | Spring Cylinder End | |
| 8 | 2654 4230 87 02 | Spring Abutment End | |
| 9 | 2654 4230 01 14 | Assy. Strut | |
| 10 | 2654 4230 01 15 | Assy. Lever Hand Brake LH | |
| 10 | 2654 4230 01 16 | Assy. Lever Hand Brake RH | |
| 11 | 2654 4230 01 19 | Assy. Wheel Cylinder (22.22 mm Dia.) | |
| 13 | 8854 4201 02 07 | Kit Lining Set (STD) Non Asbestos Consisting of : | |
| 14 | Lining (Leading) | Lining (Leading) | |
| 14 | Lining (Leading) | Lining (Leading) | |
| 14 | Lining (Leading) | Lining (Leading) | |
| 15 | Lining (Trailing) | Lining (Trailing) | |
| 15 | Lining (Trailing) | Lining (Trailing) | |
| 15 | Lining (Trailing) | Lining (Trailing) | |
| 17 | 8854 4202 02 07 | Kit Lining Set (R/S I) Non Asbestos Consisting of : | |
| 17 | 8854 4203 02 07 | Kit Lining Set (R/S II) Non Asbestos Consisting of : | |
| 18 | 2654 4230 01 12 | Kit (Cam Adjuster) Consisting of : | |
| 19 | Cam | Cam | |
| 20 | Nut | Nut | |
| 21 | Spring Washer | Spring Washer | |
| 22 | 2654 4230 01 13 | Kit Shoe Hold - Down Consisting of : | |
| 23 | Cap Washer | Cap Washer | |
| 24 | Pin | Pin | |
| 25 | Spring | Spring |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
