Каталог запасных частей к технике: Tata Telcoline-207. REAR AXLE
1
2
3
4
5
6
7
8
8
9
10
11
12
13
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
33
36
37
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2663 3500 01 55 | 2663 3500 01 55 | Assy. Dana Rear Axle complete 41/9 W/o sh abs | |
| 2654 4280 01 28 | 2654 4280 01 28 | Assy. Hose (For Remote Breather) | |
| 2663 3500 02 09 | 2663 3500 02 09 | Assy. Dana Rear Axle complete 44/9 W/o sh abs | |
| 1 | 2663 3510 01 57 | Assy. Dana Rear Axle Housing With Tube | |
| 2 | 2663 3510 32 02 | Bolt Wheel RH | |
| 3 | 2663 3510 32 03 | Retainer Bolt - 46912 | |
| 4 | 2663 3510 72 02 | Filler Plug | |
| 5 | 2663 3510 80 01 | Screw Flanged Head 34279 | |
| 6 | 2663 3510 82 03 | Cover Carrier | |
| 7 | 2663 3510 83 01 | Shim Adj. | |
| 8 | 2663 3530 01 39 | Gear Hypoid Drive Finish / Pinion Set 44/9 | |
| 8 | 2663 3530 01 34 | Gear Hypoid Drive Finish / Pinion Set 41/9 | |
| 9 | 2663 3530 31 04 | Pinion Inner Bearing | |
| 10 | 2663 3530 31 05 | Bearing Cup / Cone Roller - 550213 / 5501 | |
| 11 | 2663 3530 51 04 | Standard Differential Case | |
| 12 | 2663 3530 51 05 | Pin Role | |
| 13 | 2663 3530 01 33 | Assy Case Diff. | |
| 16 | 2663 3530 54 27 | Shaft Diff. STD - 17878 | |
| 17 | 2663 3530 77 10 | Slinger - Pinion Oil Seal (Outer) - 13575 | |
| 18 | 2663 3530 77 11 | Oil Seal | |
| 19 | 2663 3530 80 01 | Screw Hex. - 41221 | |
| 20 | 2663 3530 86 01 | Collapsable Spacer | |
| 21 | 2663 3530 86 09 | Washer Flat - 30186 | |
| 22 | 2663 3531 92 75 | Thrust Washer - Side Gear | |
| 23 | 2663 3531 92 76 | Thrust Washer Diff. Pinion - 13338 3 | |
| 24 | 2663 3535 50 03 | Assy End Yoke | |
| 25 | 2663 3535 65 02 | Nut Pinion | |
| 26 | 2663 3570 31 06 | Bearing Cup/cone ( Diff Case) | |
| 27 | 2663 3570 31 07 | Bearing Assy Taper Roller - 565904 | |
| 28 | 2663 3570 31 08 | Retainer Wheel Brg | |
| 29 | 2663 3570 43 02 | Snap Ring ( Axle Shaft ) | |
| 30 | 2663 3570 77 08 | Retainer Oil Seal - 46975 | |
| 31 | 2663 3570 77 09 | Seal Oil - Axle Shaft | |
| 33 | 2663 3570 79 02 | Shaft Axle Flange | |
| 36 | 2574 3315 01 02 | Breather | |
| 37 | 2667 3310 72 01 | Filler Plug | |
| 38 | 2667 3310 72 02 | Drain Plug | |
| 39 | 2699 4230 37 04 | Brake Drum |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
