Каталог запасных частей к технике: Tata Telcoline-207. FRONT AXLE (4x4)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
19
22
23
24
25
26
28
29
30
31
32
33
34
35
36
37
38
39
40
41
53
54
55
56
57
58
59
60
61
62
64
66
67
68
69
70
71
72
73
74
75
76
77
78
Позиция на иллюстрации Заводской номер детали Название детали
2667 3375 01 02 2667 3375 01 02 Kit For Doj End Joint Boot
2667 3375 01 01 2667 3375 01 01 Kit for RZEPPA Boot Kit, Consisting of:-
Boot Boot Boot
65 Gms Grease Packet 65 Gms Grease Packet 65 Gms Grease Packet
155 Gms Grease Packet 155 Gms Grease Packet 155 Gms Grease Packet
Clamp Clamp Clamp
Clamp Clamp Clamp
Snap Ring Snap Ring Snap Ring
Snap Ring Snap Ring Snap Ring
Snap Ring Snap Ring Snap Ring
Boot Boot Boot
110 Gms Grease Packet 110 Gms Grease Packet 110 Gms Grease Packet
155 Gms Grease Packet 155 Gms Grease Packet 155 Gms Grease Packet
Clamp Clamp Clamp
Clamp Clamp Clamp
Snap Ring Snap Ring Snap Ring
Snap Ring Snap Ring Snap Ring
Snap Ring Snap Ring Snap Ring
2667 3305 01 65 2667 3305 01 65 Assy. Front Live Axle W/O Hub-4,88 (STD)
1 2667 3350 01 01 Kit For Differential Case
2 2667 3350 51 01 Differential Case Assy
3 2667 3350 54 01 Differential Side Gear
4 2667 3350 92 01 Thrust Washer - Differential Side Gear
5 2667 3350 54 02 Differential Pinion Mate Gear
6 2667 3350 92 02 Thrust Washer
7 2667 3350 79 01 Differential Shaft STD
8 2663 3530 51 05 Pin Role
9 2667 3350 43 01 Ring Snap RH C.V. Shaft to Side Gear
10 2667 3350 43 02 Ring Snap LH C.V. Shaft to Side Gear
11 2667 3355 01 14 Ring Gear Pinion Kit (gear Ratio 4.88 ( 39/8 )
12 2667 3355 80 01 Ring Gear Screw
13 2667 3355 86 01 Collapsible Spacer
14 2663 3535 65 02 Nut Pinion
16 2667 3355 01 03 Assy Bearing (Pinion Inner)
19 2667 3355 01 04 Pinion Outer Bearing Cup /cone
22 2667 3335 82 01 Inner Slinger Pinion Oil
23 2667 3335 82 02 Outer Slinger Pinion Oil
24 2663 3530 77 11 Oil Seal
25 2667 3350 83 01 Shim Adj.
26 2667 3335 01 01 Assy End Yoke (This Includes Sl.no 52 and 53)
28 2667 3350 01 02 Differential Bearing Cup / Cone
29 2667 3310 82 01 Cover Carrier Fin
30 2667 3310 72 01 Filler Plug
31 2667 3385 37 01 Knuckle Steering LH
32 2667 3385 80 01 Bolt Hex
33 2667 3385 65 01 Nut Lock
34 2667 3385 37 02 Knuckle Steering RH
35 2667 3375 31 07 Bearing Assy w/o Race
36 2667 3375 78 04 Oil Seal
37 2667 3375 79 02 Axle Shaft Fin
38 2667 3375 31 06 Bearing Assy w/o Race
39 2667 3375 43 06 Ring Snap
40 2667 3375 01 06 Shaft And Joint Assy RH
41 2667 3375 01 07 Shaft And Joint Asembly
53 2667 3375 82 01 Shield Brake Dust RH
54 2667 3375 82 02 Shield Brake Dust LH
55 2667 3375 78 01 Oil Seal (For Hub)
56 2667 3375 01 08 Nut and Pin Assy Bearing
57 2667 3375 65 02 Lock Bearing Adj. Ring
58 2667 3375 65 01 Nut Spindle
59 2667 3375 01 11 Hub Lock Assy.
60 2667 3375 43 05 Snap Ring…..
61 2667 3375 51 01 Hub Wheel Fin
62 2667 3375 01 03 Assy Bearing (Wheel Hub Inner)
64 2667 3375 01 04 Bearing (wheel Hub Outer)
66 2667 3375 78 02 Oil Seal (In Spindle)
67 2667 3375 32 01 Wheel Bolt
68 2667 3375 79 01 Spindle Wheel Bearing
69 2667 3375 31 05 Bearing Assy w/o Race (On Spindle)
70 2667 3375 78 03 Oil Seal (In Spindle)
71 2667 3375 80 01 Hex Screw
72 2667 3375 61 01 Lock Washer
73 2699 4210 37 06 Disc Brake (Ventilated)
74 2667 3310 72 02 Drain Plug
75 2667 3375 99 04 Breather
76 2667 3315 01 09 Mounting Bracket
77 2667 3315 01 10 Mounting Bracket LH
78 2667 3305 01 63 Axle Housing Assy
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
