Каталог запасных частей к технике: Tata Telcoline-207. ENGINE GASKET KITS
1
1
1
1
2
2
3
3
4
4
5
5
5
5
6
7
8
8
8
9
9
10
11
11
11
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2547 0099 01 17 | 2547 0099 01 17 | Decarb. Gasket Kit (Euro III), Cosisting Of:- | |
| Gasket (Turbine Inlet) | Gasket (Turbine Inlet) | Gasket (Turbine Inlet) | |
| 2547 0099 01 06 | 2547 0099 01 06 | Engine Overhaul Seal Kit, Cosisting Of:- | |
| Gasket (For Egr Valve) | Gasket (For Egr Valve) | Gasket (For Egr Valve) | |
| Gasket (Turbine Inlet) | Gasket (Turbine Inlet) | Gasket (Turbine Inlet) | |
| Gasket(Turbine Outlet) | Gasket(Turbine Outlet) | Gasket(Turbine Outlet) | |
| 2547 0099 01 16 | 2547 0099 01 16 | Decarb. Gasket Kit (Euro II), Consisting of:- | |
| Gasket(Turbine Outlet) | Gasket(Turbine Outlet) | Gasket(Turbine Outlet) | |
| 1 | Cyl.Head Gasket-MLS 1.51 Thk | Cyl.Head Gasket-MLS 1.51 Thk | |
| 1 | Cyl.Head Gasket-MLS 1.63 Thk | Cyl.Head Gasket-MLS 1.63 Thk | |
| 1 | Cyl.Head Gasket-MLS 1.51 Thk | Cyl.Head Gasket-MLS 1.51 Thk | |
| 1 | Cyl.Head Gasket-MLS 1.63 Thk | Cyl.Head Gasket-MLS 1.63 Thk | |
| 2 | Gasket-Cyl.Head Cover | Gasket-Cyl.Head Cover | |
| 2 | Gasket-Cyl.Head Cover | Gasket-Cyl.Head Cover | |
| 3 | Gasket (Inlet-Ex.Manifold) | Gasket (Inlet-Ex.Manifold) | |
| 3 | Gasket (Inlet-Ex.Manifold) | Gasket (Inlet-Ex.Manifold) | |
| 4 | Washer - Injector | Washer - Injector | |
| 4 | Washer - Injector | Washer - Injector | |
| 5 | Washer (Flame Guard) | Washer (Flame Guard) | |
| 5 | Washer (Flame Guard) | Washer (Flame Guard) | |
| 5 | Washer (Flame Guard) | Washer (Flame Guard) | |
| 5 | Washer (Flame Guard) | Washer (Flame Guard) | |
| 6 | Seal Valve Guide | Seal Valve Guide | |
| 7 | Side Seal (M.b. Cap Rear) | Side Seal (M.b. Cap Rear) | |
| 8 | Oil Seal - Crankshaft Front | Oil Seal - Crankshaft Front | |
| 8 | Oil Seal - Crankshaft Front | Oil Seal - Crankshaft Front | |
| 8 | Oil Seal - Crankshaft Front | Oil Seal - Crankshaft Front | |
| 9 | Oil Seal - Crankshaft Rear | Oil Seal - Crankshaft Rear | |
| 9 | Oil Seal - Crankshaft Rear | Oil Seal - Crankshaft Rear | |
| 10 | Oil Seal - Camshaft Rear (Cover) | Oil Seal - Camshaft Rear (Cover) | |
| 11 | Oil Seal - Camshaft Front | Oil Seal - Camshaft Front | |
| 11 | Oil Seal - Camshaft Front | Oil Seal - Camshaft Front | |
| 11 | Oil Seal - Camshaft Front | Oil Seal - Camshaft Front | |
| 12 | Gasket (Therm. To Cyl. Head) | Gasket (Therm. To Cyl. Head) | |
| 12 | Gasket (Cover to Thermostate Hsg.) | Gasket (Cover to Thermostate Hsg.) |
