Каталог запасных частей к технике: Tata Telcoline-207. ENGINE COOLING
1
2
4
5
5
9
10
10
11
12
13
13
14
15
18
19
19
20
20
20
21
22
23
24
25
26
26
27
29
29
30
34
35
36
37
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2547 2014 99 03 | 2547 2014 99 03 | Adaptor (For Viscous Cl. Mtg.) | |
| 2547 2014 32 03 | 2547 2014 32 03 | Socket Head Bolt (Viscous Clutch) | |
| 2547 2014 01 24 | 2547 2014 01 24 | Viscous Clutch | |
| 1 | 2547 2010 01 18 | Assy Water Pump | |
| 2 | 2547 2010 54 01 | Gear ( Water Pump ) | |
| 4 | 2547 2010 53 06 | Gasket (Water Pump)(Betaflex Matl.) | |
| 5 | 2547 2015 37 22 | Fan Pulley (4 Groove) | |
| 5 | 2547 2015 37 21 | Fan Pulley (6PK+6PK) | |
| 9 | 2547 2014 01 23 | Assy. Fan (w/o Viscous Clutch) | |
| 10 | 2547 2012 02 04 | Assy Thermostat Housing With Adaptor | |
| 10 | 2547 2012 01 99 | Assy Thermostat Housing With Adaptor | |
| 11 | 2547 2012 53 06 | Gasket (Thermostat Hsg To Cyl Head) | |
| 12 | 2547 2012 38 10 | Cover (For Thermostat Pocket) | |
| 13 | 2547 2012 99 04 | Thermostat (83 Deg With Jiggle Pins) | |
| 13 | 2547 2012 99 08 | Thermostat (78 Deg With Jiggle Pins) | |
| 14 | 2547 2012 53 07 | Gasket (Cover To Therm Hsg ) | |
| 15 | 2547 2015 01 26 | Assy Bearing Housing - Complete | |
| 18 | 2547 2012 69 19 | Pipe (water Bypass) | |
| 19 | 2547 2012 58 11 | Rubber Hose (Thermostat To Bypass Pipe) | |
| 19 | 2547 2012 58 09 | Rubber Hose (Thermostat To Bypass Pipe) | |
| 20 | 2547 2012 42 14 | Hose Clamp ( 32 Dia ) | |
| 21 | 2547 2012 58 13 | Rubber Hose, Moulded (Elbow To Bypass) | |
| 22 | 2547 2012 42 04 | Clamp (Pipe-water Bypass) | |
| 23 | 2547 2012 33 03 | Bracket (For Water Bypass Pipe) | |
| 24 | 2659 5420 99 06 | Temp. Transducer | |
| 25 | 2547 5010 02 71 | Assy Pipe With Bracket | |
| 26 | 2534 5000 58 01 | Rubber Hose (Cover To U C Pipe) | |
| 26 | 2547 2012 58 12 | Rubber Hose- Moulded (Cover To Pipe) | |
| 27 | 2547 5010 42 22 | Hose Clamp ( 50 Dia ) | |
| 29 | 2547 5010 58 67 | Rubber Hose (Radiator Inlet)(4x4) | |
| 29 | 2547 5010 58 66 | Rubber Hose (Radiator Inlet)(4x4) | |
| 30 | 2547 5010 58 47 | Rubber Hose (Radiator To Elbow) | |
| 34 | 2547 5010 42 20 | Hose Clamp (60 Dia ) | |
| 35 | 2547 2012 53 12 | Gasket (Elbow To Crankcase) | |
| 36 | 2547 2012 01 41 | Assy Elbow Water Inlet With Banjo Body | |
| 37 | 2547 5010 58 48 | Rubber Hose (Adapter To Tube) | |
| 38 | 2547 5010 42 25 | Hose Clamp (16 dia) | |
| 39 | 2547 5010 02 74 | Assy Tube with Sleeve (Euro III) |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
