Каталог запасных частей к технике: Tata Telcoline-207. CYLINDER HEAD AND COVER

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
2
3
4
5
6
7
7
8
9
10
11
11
12
13
14
15
16
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
18
19
19
19
20
21
22
24
25
26
27
28
29
30
31
31
32
33
Позиция на иллюстрации Заводской номер детали Название детали
2 2547 0115 02 15 Assy Cylinder Head W/o Valves
3 2547 0115 34 17 Valve Seat Ring Inlet - Std.
4 2547 0115 34 20 Valve Seat Ring Exhaust - Std.
5 2547 0515 99 02 Seal Valve Guide
6 2547 0515 34 11 Valve Guide (Std)
7 2547 0110 88 01 Stud Camshaft Bearing Cap
8 2547 0115 01 35 Assy Pre Combustion Chamber
9 2547 0116 84 01 Flame Guard
10 2547 0116 92 01 Washer - Injector
11 2547 0116 01 06 Assy Nozzle (Mico)
11 2547 0116 01 11 Assy. Injector (Lucas)
12 2547 0512 51 14 Inlet Valve
13 2547 0512 51 13 Exhaust Valve
14 2547 0512 82 03 Spring Seat
15 2547 0512 51 09 Lock Retainer - Valve Spring
16 2547 0512 43 01 Valve Lock Half
17 2547 0513 83 02 Shim (2.425)
17 2547 0513 83 03 Shim (2.50)
17 2547 0513 83 04 Shim (2.575)
17 2547 0513 83 05 Shim (2.650 )
17 2547 0513 83 06 Shim (2.725 )
17 2547 0513 83 07 Shim (2.80)
17 2547 0513 83 08 Shim (2.875 )
17 2547 0513 83 09 Shim (2.950 )
17 2547 0513 83 10 Shim (3.025 )
17 2547 0513 83 11 Shim (3.10)
17 2547 0513 83 12 Shim (3.175 )
17 2547 0513 83 13 Shim (3.250 )
17 2547 0513 83 14 Shim (3.325 )
17 2547 0513 83 15 Shim (3.40)
17 2547 0513 83 16 Shim (3.475 )
17 2547 0513 83 17 Shim (3.550 )
17 2547 0513 83 18 Shim (2.40)
17 2547 0513 83 19 Shim (2.450 )
17 2547 0513 83 20 Shim (2.550)
17 2547 0513 83 21 Shim (2.60)
17 2547 0513 83 22 Shim (2.70)
17 2547 0513 83 23 Shim (2.750 )
17 2547 0513 83 24 Shim (2.850 )
17 2547 0513 83 25 Shim (2.90)
17 2547 0513 83 26 Shim (3.00)
17 2547 0513 83 27 Shim (3.050 )
17 2547 0513 83 28 Shim (3.150 )
17 2547 0513 83 29 Shim (3.20)
17 2547 0513 83 30 Shim (3.30)
17 2547 0513 83 31 Shim (3.350 )
17 2547 0513 83 32 Shim (3.450 )
17 2547 0513 83 33 Shim (3.50)
17 2547 0513 83 34 Shim (2.42)
17 2547 0513 83 35 Shim (2.44)
17 2547 0513 83 36 Shim (2.46)
17 2547 0513 83 37 Shim (2.48)
17 2547 0513 83 38 Shim (2.52)
17 2547 0513 83 39 Shim (2.54)
17 2547 0513 83 40 Shim (2.56)
17 2547 0513 83 41 Shim (2.58)
17 2547 0513 83 42 Shim (2.62)
17 2547 0513 83 43 Shim (2.64)
17 2547 0513 83 44 Shim (2.66)
17 2547 0513 83 45 Shim (2.68)
17 2547 0513 83 46 Shim (2.72)
17 2547 0513 83 47 Shim (2.74)
17 2547 0513 83 48 Shim (2.76)
17 2547 0513 83 49 Shim (2.78)
17 2547 0513 83 50 Shim (2.82)
17 2547 0513 83 51 Shim (2.84)
17 2547 0513 83 52 Shim (2.86)
17 2547 0513 83 53 Shim (2.88)
17 2547 0513 83 54 Shim (2.92)
17 2547 0513 83 55 Shim (2.94)
17 2547 0513 83 56 Shim (2.96)
17 2547 0513 83 57 Shim (2.98)
17 2547 0513 83 58 Shim (3.02)
17 2547 0513 83 59 Shim (3.04)
17 2547 0513 83 60 Shim (3.06)
17 2547 0513 83 61 Shim (3.08)
17 2547 0513 83 62 Shim (3.12)
17 2547 0513 83 63 Shim (3.14)
17 2547 0513 83 64 Shim (3.16)
17 2547 0513 83 65 Shim (3.18)
17 2547 0513 83 66 Shim (3.22)
17 2547 0513 83 67 Shim (3.24)
17 2547 0513 83 68 Shim (3.26)
17 2547 0513 83 69 Shim (3.28)
17 2547 0513 83 70 Shim (3.32)
17 2547 0513 83 71 Shim (3.34)
17 2547 0513 83 72 Shim (3.36)
17 2547 0513 83 73 Shim (3.38)
17 2547 0513 83 74 Shim (3.42)
17 2547 0513 83 75 Shim (3.44)
17 2547 0513 83 76 Shim (3.46)
17 2547 0513 83 78 Shim (3.54)
17 2547 0513 83 79 Shim (3.56)
18 2547 1518 99 02 Glow Plug (Mico)
19 2547 0115 53 61 Cyl. Head Gasket- MLS (1.5 Thk)
19 2547 0115 53 62 Cyl. Head Gasket-MLS (1.6 Thk)
19 2547 0115 53 69 Cyl. Head Gasket-MLS (1.7 Thk)
20 2547 0115 80 01 Collar Screw
21 2549 0115 92 01 Washer (Cyl Head Bolt)
22 2547 0115 01 34 Assy Cylinder Head Cover With Tube
24 2547 0115 53 24 Gasket (Cyl. Head Cover)
25 2547 0115 01 28 Assy Sealing Washer (Cyl. Head Cover)
26 2547 0115 69 03 Spacer Tube (75 mm Long)
27 2547 0115 69 04 Spacer Tube (94 mm Long)
28 2547 0115 88 05 Stud (M6x100)
29 2547 0115 88 06 Stud (M6x120)
30 2547 0115 92 04 Washer (Cyl. Head Cover)
31 2547 0110 82 03 Core Plug ( 32 Dia )
31 2547 0110 82 04 Core Plug ( 27 Dia )
32 2547 0512 87 06 Valve Spring
33 2547 0116 92 04 Washer-Flame Guard
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
