Каталог запасных частей к технике: Lifan LF-LF7161A Breez 1,6H. Safety belts
1
1
1
1
1
1
1-1
1-1
1-1
2
2
2
2
2
2
3
3
3
3
4
4
4
4
5
5
6
6
8
8
8
8
9
9
9
9
10
10
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | L5811100B10 | Left safety belt | |
| 1 | L5811100B02 | Left safety belt | |
| 1 | LAA5811100B1B10 | Left safety belt | |
| 1 | LAA5811100B1B02 | Left safety belt | |
| 1 | LAX5811100B1B10 | Left safety belt | |
| 1 | LAX5811100B1B10 | Left safety belt | |
| 1-1 | L5811102B10 | Safety belt cap | |
| 1-1 | L5811102B02 | Safety belt cap | |
| 2 | L5811200B10 | Right safety belt | |
| 2 | L5811200B02 | Right safety belt | |
| 2 | LAA5811200B1B10 | Right safety belt | |
| 2 | LAA5811200B1B02 | Right safety belt | |
| 2 | LAX5811200B1B10 | Right safety belt | |
| 2 | LAX5811200B1B10 | Right safety belt | |
| 3 | L5811101B10 | Left safety belt buckle | |
| 3 | L5811101B02 | Left safety belt buckle | |
| 3 | LAA5811101B1B10 | Left safety belt buckle | |
| 3 | LAA5811101B1B02 | Left safety belt buckle | |
| 4 | L5811201B10 | Right safety belt buckle | |
| 4 | L5811201B02 | Right safety belt buckle | |
| 4 | LAA5811201B1B10 | Right safety belt buckle | |
| 4 | LAA5811201B1B02 | Right safety belt buckle | |
| 5 | 231-(7/16)"35TF3 | Hex flange bolt | |
| 6 | LCA5812110B10 | Rear safety belt, left | |
| 6 | LCA5812110B02 | Rear safety belt, left | |
| 7 | Q1410616L | Hex bolt and taper springness washer | |
| 8 | LCA5812120B10 | Rear safety belt buckle, left | |
| 8 | LCA5812120B02 | Rear safety belt buckle, left | |
| 8 | LCA5812120A2B10 | Rear safety belt buckle, left | |
| 8 | LCA5812120A2B02 | Rear safety belt buckle, left | |
| 9 | LCA5812220B10 | Rear safety belt buckle, right | |
| 9 | LCA5812220B02 | Rear safety belt buckle, right | |
| 9 | LCA5812220A2B10 | Rear safety belt buckle, right | |
| 9 | LCA5812220A2B02 | Rear safety belt buckle, right | |
| 10 | LCA5812210B10 | Rear safety belt, right | |
| 10 | LCA5812210B02 | Rear safety belt, right |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
