Каталог запасных частей к технике: Lifan LF-LF7161A Breez 1,6H. Engine mount
1
2
2
2
2
2
2
2
2
2
2
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
18
19
20
20
20
21
21
22
23
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LAL1001320 | Left suspension bracket, upper | |
| 2 | 231-1025TF3 | Hex flange bolt | |
| 3 | LAL1001330 | Left suspension bracket, lower | |
| 4 | 133-1212 | Nut | |
| 5 | 231-1292TF3 | Hex flange bolt | |
| 6 | LAL1001310 | Left suspension component | |
| 7 | LAL1001340 | Left suspension bracket | |
| 8 | LAL1001230 | Rear suspension bracket | |
| 9 | 101-1212T2F3 | Hex flange nut | |
| 10 | 231-12100TF3 | Hex flange bolt | |
| 11 | LAL1001210 | Rear suspension component | |
| 12 | 214-1030TF30 | Hex bolt and washer | |
| 13 | 214-1035TF30 | Hex bolt and washer | |
| 14 | Q33010T13F3 | Nut | |
| 15 | LBA1001401 | Right suspension bracket | |
| 16 | LBA1001430 | Right suspension stopper | |
| 17 | LBA1001420 | Right suspension component | |
| 18 | Q1841025TF30 | Hex flange bolt | |
| 19 | LBA1001410 | Right suspension bracket | |
| 20 | Q340B10 | I hex nut | |
| 21 | 215-1035TF30 | Hex flange bolt and washer | |
| 22 | 231-1040TF30 | Hex flange bolt | |
| 23 | GB/T889.2 | I non metal hex lock nut |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
