Каталог запасных частей к технике: Lifan LF-7162C Solano. Rear seat

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
1
2
2
2
2-1
2-1
2-2
2-2
3
3
3
3-1
3-1
3-2
3-2
3-3
3-3
4
4
4
5
5
5
6
7
8
Позиция на иллюстрации Заводской номер детали Название детали
1 B7005400B15 Rear seat right side rest
1 B7005400A2B15 Rear seat right side rest
1 B7005400A3B15 Rear seat right side rest
2 B7005200B15 Rear seat right back rest assy
2 B7005200A2B15 Rear seat right back rest assy
2 B7005200A3B15 Rear seat right back rest assy
2-1 B7008100 Rear seat pillow
2-1 B7008100A2 Rear seat pillow
2-2 B7005211 Rear seat right back rest
2-2 B7005211A2 Rear seat right back rest
3 B7005100B15 Rear seat left back rest assy
3 B7005100A2B15 Rear seat left back rest assy
3 B7005100A3B15 Rear seat left back rest assy
3-1 B7008100 Rear seat pillow
3-1 B7008100A2 Rear seat pillow
3-2 B7005111 Rear seat left back rest
3-2 B7005111A2 Rear seat left back rest
3-3 B7006100 Middle handrail
3-3 B7006100A2 Middle handrail
4 B7005300B15 Rear seat left side rest
4 B7005300A2B15 Rear seat left side rest
4 B7005300A3B15 Rear seat left side rest
5 B7003000B15 Rear seat cushion
5 B7003000A2B15 Rear seat cushion
5 B7003000A3B15 Rear seat cushion
6 B7007111 Left hinge, rear seat
7 B7007300 Middle hinge, rear seat
8 B7007211 Right hinge, rear seat
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
