Каталог запасных частей к технике: Lifan LF-7162C Solano. Cylinder head cover
1
1-1
1-2
1-3
1-4
1-5
2
2-1
2-2
3
4
5
6
7
8
9
10
11
12
13
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LF479Q1-1003200A1 | Cylinder head cover assy | |
| 1-1 | LF479Q1-1003210A | Cylinder head cover | |
| 1-2 | LF479Q1-1003202A | Nozzle, cylinder head cover | |
| 1-3 | LF479Q1-1003212A | Oil baffle I | |
| 1-4 | LF479Q1-1003213A | Oil baffle II | |
| 1-5 | Bolt | Bolt | |
| 2 | LF479Q1-1003230A | Oil filler cap assy | |
| 2-1 | LF479Q1-1003201A | Cap, oil filler | |
| 2-2 | LF479Q1-1003204A | Gasket | |
| LF479Q1-3707000A | LF479Q1-3707000A | Ignition cable suite | |
| 3 | LF479Q1-3707100A | Ignition cable 1 | |
| 4 | LF479Q1-3707200A | Ignition cable 2 | |
| 5 | LF479Q1-3707300A | Ignition cable 3 | |
| 6 | LF479Q1-3707400A | Ignition cable 4 | |
| 7 | LF479Q1-1014011A | PCV vent hose | |
| 8 | LBA1109012 | Longe hose | |
| 9 | LF479Q1-1014100A | PCV assy | |
| 10 | LF479Q1-1003015A | Gasket,cylinder head cover | |
| 11 | LF479Q1-1003018A | Cylinder head cover nut | |
| 12 | LF479Q1-1003017A | Cylinder head cover bolt gasket | |
| 13 | LF479Q1-1014014A | PCV seal | |
| LF479Q1-1003203A | LF479Q1-1003203A | Seal, cylinder head cover |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
