Каталог запасных частей к технике: Lifan LF-7162 Solano. Side body
1
2
3
4
5
6
7
8
8
9
10
10
11
11
12
12
13
13
14
14
15
15
16
17
18
18-1
18-2
18-3
18-4
19
19
20
21
22
22
23
23
24
25
26
26
27
28
28
29
30
30
31
31
32
32
33
34
35
35
36
37
38
38
39
39
39
39
40
40
41
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Q2215519F31 | Philips screw with washer | |
| 2 | 400-065 | Plastic clip | |
| 3 | B5416225 | Skirt plate plug | |
| 4 | B5416223 | Skirt plate clip | |
| 5 | B5416224 | Skirt plate clip | |
| 6 | B5416226 | Skirt plate plug | |
| 7 | B5400113 | Sound proof cushion | |
| 8 | B5416222 | Seal, right triangular window decoration | |
| 8 | B5416212 | Seal, left triangular window decoration | |
| 9 | 400-1405 | Plastic clip | |
| 10 | B5416221 | Right triangular window decoration | |
| 10 | B5416211 | Left triangular window decoration | |
| 11 | B5402021 | Roof support, front right | |
| 11 | B5402011 | Roof support, front left | |
| 12 | B6107217 | Front right door frame seal | |
| 12 | B6107117 | Front left door frame seal | |
| 13 | B5402230B15 | Right upper fender, B pillar | |
| 13 | B5402130B15 | Left upper fender, B pillar | |
| 14 | B5402022 | Roof support, rear right | |
| 14 | B5402012 | Roof support, rear left | |
| 15 | B6207217 | Rear right door frame seal | |
| 15 | B6207117 | Rear left door frame seal | |
| 16 | B5107111 | Plug | |
| 17 | Q72725 | Rubber plug | |
| 18 | B8123630 | Trunk ventilation | |
| 18-1 | B8123631 | Trunk ventilation frame | |
| 18-2 | B8123632 | Trunk ventilation seal I | |
| 18-3 | B8123633 | Trunk ventilation seal II | |
| 18-4 | B5400121 | Plastic nut, side bdoy | |
| 19 | B5402250B15 | Right upper fender, C-pillar | |
| 19 | B5402150B15 | Left upper fender, C-pillar | |
| 20 | 400-1729 | Plastic clip | |
| 21 | 400-256 | Plastic clip | |
| 22 | B5400341 | Rear right mudguard | |
| 22 | B5400331 | Rear left mudguard | |
| 23 | B5400342 | Spray-proof, rear right mudguard | |
| 23 | B5400337 | Spray-proof, rear left mudguard | |
| 24 | B5400338 | Clip, rear spray-proof | |
| 25 | Q2754820 | Philips self-tapping screw | |
| 26 | B5400343 | Rear right decoration, mudguard | |
| 26 | B5400339 | Rear left decoration, mudguard | |
| 27 | 400-1500 | Plastic clip | |
| 28 | B5402181B15 | Rear left threshold fender | |
| 28 | B5402281B15 | Rear right threshold fender | |
| 29 | B5400112 | B pillar cushion | |
| 30 | B5402241B15 | Right lower fender, B-pillar | |
| 30 | B5402141B15 | Left lower fender, B-pillar | |
| 31 | B5402171B15 | Front left threshold fender | |
| 31 | B5402271B15 | Front right threshold fender | |
| 32 | B5402220B15 | Right lower fender, A-pillar | |
| 32 | B5402120B15 | Left lower fender, A-pillar | |
| 33 | Q1840620 | Hex flange bolt | |
| 34 | B5400316 | Small mudguard | |
| 35 | B5400321 | Front right mudguard | |
| 35 | B5400311 | Front left mudguard | |
| 36 | B5400315 | Fixing plate | |
| 37 | 400-1933 | Plastic clip | |
| 38 | B6105141 | Door buckle component | |
| 39 | 327-0820 | Inner hex flat head screw | |
| 40 | B5402211B15 | Right upper fender, A-pillar | |
| 40 | B5402111B15 | Left upper fender, A-pillar | |
| 41 | 400-540 | Plastic clip |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
