Каталог запасных частей к технике: Lifan LF-7162 Solano. Rear right door attachment

Тип техники

Марка

Модель

Схема

1-1

1-2

1-3

1-4

1-5

2-1

2-2

2-3

2-4

Позиция на иллюстрации	Заводской номер детали	Название детали
1	B6205230A2	Outer handle assy, rear right door
1-1	B6105131	Outer handle
1-2	B6205222	Door outer handle B, rear right door
1-3	B6105133	Plastic ring B, door handle
1-4	B6105132	Plastic ring A, door handle
1-5	B6205225	Handle seat, rear right door
2	B6200220	Glass rail assy, rear right door
2-1	B6200221	Glass rail, rear right door
2-2	B6200222	Glass rail bracket, rear right door
2-3	321-0508	Philips screw
2-4	B6200227	Glass rail sleeve, rear right door
3	B6203212	Triangular glass, rear right door
4	Q1840610	Hex flange bolt
5	Q2400820	Philips screw and washer
6	B6109112	Door damper
7	B6105141	Door buckle component
8	B6207213	Triangular glass seal, rear right door
9	B6207211	Glass seal, rear right door
10	B6207214	Rear right door seal
11	B6107114	Door seal clip A
12	B6202217	Inner handrail cushion, rear right door
13	B6202118	Rear door screw cap
14	Q2734216	Philips self-tapping screw
15	B3746400	Inner handrail with switches, rear right door
16	Q2734216	Philips self-tapping screw
17	B6105400	Inner handle, rear right door
18	B6202211	Interior trim, rear right door
19	B6202210B97	Rear right door interior
20	400-540	Plastic clip
21	B6202020	Rain shield, rear right door
22	Q2540508	Philips screw
23	Q398B03	Plastic nut
24	Q1840610	Hex flange bolt
25	B6206220	Lower hinge, Rear right door
26	Q1840820	Hex flange bolt
27	Q1840816T1F30	Hex flange bolt
28	B6209100	Rear door stopper
29	Q1840820	Hex flange bolt
30	B6206210	Upper hinge, Rear right door
31	B6203200	Rear right door glass
32	B6205210	Rear door lock
32	B6205210B1	Rear door lock
33	B6207212	Weather Strip, rear right door
34	B6204200	Glass lifter, rear right door
