Каталог запасных частей к технике: Lifan LF-7162 Solano. Output shaft
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | L1701446A1 | First, second gear synchronize outer rim | |
| 2 | L1701447A1 | First, second gear synchronize taper rim | |
| 3 | L1701448A1 | First, second gear synchronize inner rim | |
| 4 | L1701420A1 | First driven gear assy | |
| 5 | L1701459A1 | Needle bearing | |
| 6 | L1701411A1 | Output shaft | |
| 7 | L1701313A1 | Oil guide plug | |
| 8 | L1701453A1 | Fifth driven gear circlip | |
| 9 | L1701452A1 | Fifth driven gear assy | |
| 10 | L1701451A1 | Third, forth duplicate gear | |
| 11 | L1701430A1 | Second driven gear assy | |
| 12 | L1701441A1 | First, second gear synchronize sleeve | |
| 13 | L1701456A1 | First, second gear hub circlip | |
| 14 | L1701443A1 | Steel ball | |
| 15 | L1701444A1 | Spring | |
| 16 | L1701445A1 | Slider | |
| 17 | L1701442A1 | First, second gear hub |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
