Каталог запасных частей к технике: Lifan LF-7160L1 Breez 1,6. Safety belt
1
1
1
1
1
1
1-1
1-1
2
2
2
2
2
2
2-1
2-1
3
3
3
3
4
4
4
4
5
5
6
6
6
6
7
8
8
8
8
8
9
9
9
9
9-1
9-1
9-1
9-1
9-2
9-2
9-2
9-2
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | L5811100B10 | Left safety belt | |
| 1 | L5811100B02 | Left safety belt | |
| 1 | LAA5811100B1B10 | Left safety belt | |
| 1 | LAA5811100B1B02 | Left safety belt | |
| 1 | LAX5811100B1B10 | Left safety belt | |
| 1 | LAX5811100B1B02 | Left safety belt | |
| 1-1 | L5811102B02 | Safety belt cap | |
| 1-1 | L5811102B10 | Safety belt cap | |
| 2 | L5811200B10 | Right safety belt | |
| 2 | L5811200B02 | Right safety belt | |
| 2 | LAA5811200B1B10 | Right safety belt | |
| 2 | LAA5811200B1B02 | Right safety belt | |
| 2 | LAX5811200B1B10 | Right safety belt | |
| 2 | LAX5811200B1B02 | Right safety belt | |
| 2-1 | L5811102B02 | Safety belt cap | |
| 2-1 | L5811102B10 | Safety belt cap | |
| 3 | L5811101B02 | Left safety belt buckle | |
| 3 | L5811101B10 | Left safety belt buckle | |
| 3 | LAA5811101B1B02 | Left safety belt buckle | |
| 3 | LAA5811101B1B10 | Left safety belt buckle | |
| 4 | L5811201B02 | Right safety belt buckle | |
| 4 | L5811201B10 | Right safety belt buckle | |
| 4 | LAA5811201B1B02 | Right safety belt buckle | |
| 4 | LAA5811201B1B10 | Right safety belt buckle | |
| 5 | 231-(7/16)"35TF3 | Hex flange bolt | |
| 6 | L5812000B02 | Rear safety belt | |
| 6 | L5812000B10 | Rear safety belt | |
| 6 | LAA5812000B1B02 | Rear safety belt | |
| 6 | LAA5812000B1B10 | Rear safety belt | |
| 7 | Q1410616L | Hex bolt and taper springness washer | |
| 8 | L5812101B02 | Rear safety belt buckle | |
| 8 | L5812101B10 | Rear safety belt buckle | |
| 8 | LAA5812101B1B02 | Rear safety belt buckle | |
| 8 | LAA5812101B1B10 | Rear safety belt buckle | |
| 9 | L5813100B02 | Middle safety belt assy | |
| 9 | L5813100B10 | Middle safety belt assy | |
| 9 | LAA5813100B1B02 | Middle safety belt assy | |
| 9 | LAA5813100B1B10 | Middle safety belt assy | |
| 9-1 | L5813101B02 | Middle safety belt | |
| 9-1 | L5813101B10 | Middle safety belt | |
| 9-1 | LAA5813101B1B02 | Middle safety belt | |
| 9-1 | LAA5813101B1B10 | Middle safety belt | |
| 9-2 | L5813102B02 | Middle safety belt buckle | |
| 9-2 | L5813102B10 | Middle safety belt buckle | |
| 9-2 | LAA5813102B1B02 | Middle safety belt buckle | |
| 9-2 | LAA5813102B1B10 | Middle safety belt buckle |
