Каталог запасных частей к технике: Lifan LF-7160L1 Breez 1,6. Rear attachment

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
3
4
4
4
5
5
5
5
5
5
5
5
6
7
8
8
8
8
8
8
8
8
9
10
11
12
13
13
13
13
14
14
15
15
15
16
17
18
19
20
21
21
22
22-1
22-2
24
25
26
27
28
28
29
29
29
30
31
32
32
33
33
33-1
33-2
33-3
33-4
33-4
33-4
33-4
34
35
35
35
36
36
37
37
37
38
Позиция на иллюстрации Заводской номер детали Название детали
1 L5603101 Rear windshield
2 L5603102 Rear windshield seal
3 L5608304A2 Trunk side damper pad
4 L5608405B02 Left safty belt sleeve
4 L5608405B10 Left safty belt sleeve
5 L5608400B01 Trunk shelf panel
5 L5608400B02 Trunk shelf panel
5 L5608400B1B01 Trunk shelf panel
5 L5608400B1B02 Trunk shelf panel
5 L5608400C1B01 Trunk shelf panel
5 L5608400C1B02 Trunk shelf panel
5 L5608400D1B01 Trunk shelf panel
5 L5608400D1B02 Trunk shelf panel
L5608407 L5608407 Trunk shelf support, left
L5608408 L5608408 Trunk shelf support, right
6 L5608201 Trunk side trim, right
7 L5605102 Trunk lid hinge shaft
8 L5608103B01 Plastic inlay clip
8 L5608103B02 Plastic inlay clip
9 L5608101 Trunk side trim, left
10 L5605102 Trunk lid hinge shaft
11 L8212011 Rear left mud guard
12 L8212081 Mud guard bracket, rear left
13 L8212012 Inlay button
14 305-4820F30 Screw
15 Q39748202 Spring nut
16 L5608302 Spare tyre cover
17 L5608301 Trunk carpet
18 L8212021 Rear left mud guard
19 L8212051 Mud guard bracket, rear right
20 Q1460525 Hex bolt and washers
21 L8402021 Dmaper block
22 L5606100 Trunk lock system
22-1 L5606120 Trunk lock
22-2 L5606101 Trunk lock cap
24 L5602013 Trunk lid inner trim
25 L5602012 Plastic clip
26 L5606300 Trunk lock buckle
27 L5602011 Rear skirt panel trim
28 L8112102A1 Screw
29 Q150B0620T1F30 Hex bolt
30 Q31206 Nut
31 L2804101 Rear bumper damper
32 L2804011 Rear bumper
32 L2804011B1 Rear bumper
33 L5506100 License plate trim assy
33 L5506100B1 License plate trim assy
33-1 L5506102 Seal, lisence plate trim
33-2 L5506103 Trunk handle
33-3 Q2580616T1F30 Screw
33-4 L5506101 License plate trim
33-4 L5506101A2 License plate trim
33-4 L5506101B1 License plate trim
33-4 L5506101B2 License plate trim
34 Q32006 Hex flange bolt
35 Q40206F30 Washer
36 L5605120B1 Trunk lid pneumatic spring
37 L5604401 Trunk seal
38 L5604405 Clip
