Каталог запасных частей к технике: Lifan LF-7160L1 Breez 1,6. Fuel supply system
1
1
1
1
1
1
1
1
1
1
1
1
2
3
3
3-1
4
5
6
7
8
9
10
11
11
11
12
12
12
12
13
14
15
16
17
17
18
19
20
21
22
23
24
24
24-1
24-2
24-3
24-4
24-5
24-6
24-7
24-8
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Q67512 | Hoop | |
| 2 | LBA1130107C1 | Hose V | |
| 3 | LBA1130310 | Canister Control Valve | |
| 3 | LBA1130310B1 | Canister Control Valve | |
| 3-1 | LBA1130311B1 | Canister control valve sleeve | |
| 4 | LBA1130108 | Hose VI | |
| LBA1130108C1 | LBA1130108C1 | Hose VI | |
| 5 | L1130200 | Canister | |
| 6 | Q673B13 | Hoop | |
| 7 | L1130111C1 | Canister hose | |
| 8 | LBA1104120D1 | Fuel outlet hose III | |
| LBA1104120C1 | LBA1104120C1 | Fuel outlet hose III | |
| 9 | BL247 | Tie | |
| 10 | LBA1130130C1 | Hose IV | |
| 11 | L1104015 | Plastic clip | |
| 12 | L1104012 | Tube clip | |
| 13 | L1104140C1 | Fuel outlet plastic tube | |
| 14 | L1130120C1 | Plastic tube | |
| 15 | L1130101C1 | Hose I | |
| 16 | L1104011C1 | Fuel tank hose | |
| 17 | Q67525 | Hoop | |
| 18 | L1104110C1 | Fuel outlet hose I | |
| 19 | L1104130C1 | Fuel return hose | |
| 20 | L1117100 | Fuel filter | |
| 21 | L1104101C1 | Fuel outlet hose II | |
| 22 | Q67407100 | Tie | |
| 23 | Q32206 | Hex bolt and taper springness washer | |
| 24 | L1101200C1 | Fuel filler pipe assy | |
| 24 | L1101200D1 | Fuel filler pipe assy | |
| 24-1 | L1101202 | Connecting hose | |
| 24-2 | L1101212 | Rubber seal | |
| 24-3 | L1101206 | Fuel filler pipe | |
| 24-4 | L1101203 | Drain hose | |
| 24-5 | L1101204 | Hose II | |
| 24-6 | L1101205 | Hose III | |
| 24-7 | L1101201 | Hose connecting fuel filler and tank | |
| 24-8 | Q67570 | Hoop |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
