Каталог запасных частей к технике: Lifan LF-7131A Breez 1,3. Steering system

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1-1
2
2
3
4
4
5
6
7
7
8
8
9
10
10-1
10-2
10-3
10-4
10-5
11
12
13
14
14-1
14-2
14-3
14-4
15
15
16
17
17
18
18
19
20
21
21
21
22
22-1
22-1
22-2
22-3
22-4
22-5
23
24
25
26
26
27
28
29
30
30
31
31
32
33
Позиция на иллюстрации Заводской номер детали Название детали
1 LBA3408000 Steering oil reservior
1-1 LBA3408012 Steering oil reservior cap
2 Q67516 Hoop
3 LBA3406300B1 Steering oil return pipe assy
4 Q67525 Hoop
5 LBA3406100B1 Steering pump oil inlet pipe
6 L3612340 Power steering switch
7 Q32810T13F3 Nut
8 Q40010 Washer
9 LBA3406200B1 Steering gear oil inlet pipe
10 LBA3407100 Power steering pump
10-1 Q150B1030 Hex bolt
10-2 Q40310 Springness washer
10-3 507-1024 Flat washer
10-4 LBA3407110 Power steering pump pulley
10-5 Q1460816 Hex bolt and washer
11 LBA3407102 Steering pump adjustor
12 231-1020TIF3 Hex flange bolt
13 LBA3407103 Belt, steering pump
14 LBA3407101 Steering pump bracket
14-1 Q150B1080 Hex bolt
14-2 Q40310 Springness washer
14-3 Q340B10 I hex nut
14-4 LBA3407101 Steering pump bracket
15 Q1410825L Hex bolt and taper springness washer
16 231-1025T1F3 Hex flange bolt
17 231-1075TF3 Hex flange bolt
18 Q33008T13F3 Nut
19 Q1410840TF3 Hex bolt and taper elastic washer
20 Q1410616L Hex bolt and taper springness washer
21 204-0825T1F3 Hex bolt and taper springness washer
22 LBA3406821 Steering oil return pipe bracket II
22-1 L3406304 Steering oil return pipe sleeve
22-2 L3406201 Steering oil return pipe clip
22-3 L3406301 Steering oil return pipe bracket
22-4 Q1410616L Hex bolt and taper springness washer
22-5 Q340B06 Hex nut
23 Q40206 Big washer
24 Q32208T13F3 Hex nut and taper elastic washer
25 LAX3403100 Steering gear bracket
26 Q33006 Allmetal hex flange locknut
27 204-0870T1F3 Hex bolt and taper elastic washer
28 204-0885T1F3 Hex bolt and taper elastic washer
29 L3404300 Steering gear dust sleeve
30 L3404100 Upper steering shaft assy
30 L3404100B1 Upper steering shaft assy
31 L3404200 Lower steering shaft assy
31 L3404200B1 Lower steering shaft assy
32 199-10115T1F3 Nut
33 L3401011 Square washer
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
