Каталог запасных частей к технике: Lifan LF-7131A Breez 1,3. Rear seat
1
1
1
1
1
2
2
3
4
4
4
4
4
5
6
6-1
6-2
7
8
8
8
8
9
9
10
10
11
11
11
12
13
13
13
13
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LCA7008100B01 | Rear pillow | |
| 1 | LCA7008100B02 | Rear pillow | |
| 1 | LCA7008100A2B01 | Rear pillow | |
| 1 | LCA7008100A2B02 | Rear pillow | |
| 2 | LCA7007013 | Rear seat backrest buckle | |
| 3 | LCA7005120 | Rear seat backrest locker, right | |
| 4 | 301-0823T1F30 | Screw | |
| 5 | LCA7007012 | Rear seat backrest bracket, right | |
| 6 | LCA7005130 | Rear seat backrest switch | |
| 6-1 | LCA7005131 | Rear seat backrest switch button | |
| 6-2 | LCA7005132 | Rear seat backrest switch seat | |
| 7 | LCA7007011 | Rear seat backrest bracket, left | |
| 8 | LCA7003000B01 | Rear seat cushion | |
| 8 | LCA7003000B02 | Rear seat cushion | |
| 8 | LCA7003000A2B01 | Rear seat cushion | |
| 8 | LCA7003000A2B02 | Rear seat cushion | |
| 9 | L5130833 | Hook sleeve | |
| 10 | L5130832 | Rear seat mount hook | |
| 11 | Q32208T13F3 | Hex nut and taper elastic washer | |
| 12 | LCA7005110 | Rear seat backrest locker, left | |
| 13 | LCA7005100B01 | Rear seat backrest | |
| 13 | LCA7005100B02 | Rear seat backrest | |
| 13 | LCA7005100A2B01 | Rear seat backrest | |
| 13 | LCA7005100A2B02 | Rear seat backrest |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
