Каталог запасных частей к технике: Lifan LF-7130A1 Breez 1,3. Valve timing mechanism
1
2
3
4
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LF479Q1-1006105A | Intake timing gear | |
| 2 | LF479Q1-1006103A | Backlash spring | |
| 3 | LF479Q1-1006101A | Intake Camshaft | |
| 4 | LF479Q1-1007018A | Intake valve seal | |
| 5 | LF479Q1-1007021A-19 | Shim | |
| 5 | LF479Q1-1007021A-24 | Shim | |
| 5 | LF479Q1-1007021A-23 | Shim | |
| 5 | LF479Q1-1007021A-22 | Shim | |
| 5 | LF479Q1-1007021A-21 | Shim | |
| 5 | LF479Q1-1007021A-20 | Shim | |
| 5 | LF479Q1-1007021A-18 | Shim | |
| 5 | LF479Q1-1007021A-17 | Shim | |
| 5 | LF479Q1-1007021A-16 | Shim | |
| 5 | LF479Q1-1007021A-15 | Shim | |
| 5 | LF479Q1-1007021A-14 | Shim | |
| 5 | LF479Q1-1007021A-13 | Shim | |
| 5 | LF479Q1-1007021A-11 | Shim | |
| 5 | LF479Q1-1007021A-10 | Shim | |
| 5 | LF479Q1-1007021A-9 | Shim | |
| 5 | LF479Q1-1007021A-8 | Shim | |
| 5 | LF479Q1-1007021A-7 | Shim | |
| 5 | LF479Q1-1007021A-6 | Shim | |
| 5 | LF479Q1-1007021A-5 | Shim | |
| 5 | LF479Q1-1007021A-4 | Shim | |
| 5 | LF479Q1-1007021A-3 | Shim | |
| 5 | LF479Q1-1007021A-2 | Shim | |
| 5 | LF479Q1-1007021A-1 | Shim | |
| 5 | LF479Q1-1007021A-12 | Shim | |
| 6 | LF479Q1-1007019A | Tappet | |
| 6 | LF479Q3-1007020A | Tappet | |
| 7 | LF479Q1-1007016A | Valve Lock | |
| 8 | LF479Q1-1007015A | Valve Spring Retainer | |
| 9 | LF479Q1-1007013A | Valve Spring | |
| 10 | LF479Q1-1007017A | Exhaust Valve Seal | |
| 11 | LF479Q1-1003121A | Valve Guide | |
| 12 | LF479Q1-1007014A | Valve Spring Seat | |
| 13 | LF479Q1-1007011A | Exhaust Valve | |
| 14 | LF479Q1-1007012A | Intake Valve | |
| 15 | LF479Q1-1006202A | Exhaust timing gear | |
| 16 | LF479Q1-1006201A | Exhaust Camshaft | |
| 17 | LF479Q1-1006203A | Exhaust gear snap ring | |
| 18 | LF479Q1-1006011A | Camshaft shaft seal | |
| 19 | LF479Q1-1006107A | Exhaust gear snap ring | |
| 20 | LF479Q1-1006104A | Wave Washer | |
| 21 | LF479Q1-1006106A | Intake timing sub gear |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
