Каталог запасных частей к технике: Lifan LF-7130A1 Breez 1,3. Transmission shell

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано BYD Chevrolet Daewoo Geely Great Wall Hyundai Lifan Tata АЗЛК ВАЗ ГАЗ ЗАЗ ЗИЛ ИЖ ЛуАЗ РАФ УАЗ

Модель Не выбрано LF-7130A1 Breez 1,3 (2009) LF-7131A Breez 1,3 (2010) LF-7160L1 Breez 1,6 (2009) LF-7162 Solano (2009) LF-7162C Solano (2009) LF-LF7161A Breez 1,6H (2009)

Схема > Не выбрано Cylinder head cover Cylinder head Cylinder block Valve timing mechanism Crankshaft and piston rod Timing agency and front cover Oil pan In-manifold In-manifold (plastic) Ex-manifold Thermostat Pulley system Water pump Starter and Generator Auxiliary device Clutch Oil pump Engine harness EFI system Engine assy (without Transmission) Transmission assy Clutch shell Transmission axle Output shaft Input shaft Transmission shell Differential Engine suspension Front suspension Front shock absorber Rear axle Rear suspension Propeller shaft Shift system Clutch system Steering system Steering gear Fuel supply system Air filter Accelerator mechanism Fuel tank Brake system (EABS) Brake system (MABS) Brake system (proportional valve) Brake pump assy Brake pedal Front brake Rear brake Radiator Cooling line Exhaust system Wheels (steel) Wheels (aluminum) Electrical equipment in front compartment Battery Center control box and security system Electrical equipment in dashboard Reverse monitor system Wiper and lamp combination switch Inner handrail switch Windows glass lifter motor Console Lock and keys Communication and A/V device Vehicle lamps Defrost wire Headlining harness Generator B wire Rear harness Front harness Right floor harness Battery negative wire Dashborad harness Rear door harness Brake shoe worm inspection harness Left body harness Left door harness ABS sensor Airbag harness Vehicle body assy Engine hood Radiator beam Anti-collision beam Dash panel Left front longeron and front wheel house Right front longeron and front wheel house Roof Left cowl Right cowl Front left door Rear left door Front right door Rear right door Front floor Rear floor Rear cowl Trunk shelf plate Trunk lid Front fender panel Engine hood attachment Front cowl attachment (upper) Front cowl attachment (lower) Windshield wiper Windshield washer Dashboard trims Console trims Glovebox Steering wheel and Airbags Headlining Left side body attachment Right side body attachment Front door attachment Rear door attachment Rear attachment Floor attachment Driver's seat Passenger's seat Rear seat Safety belt Logo emblem A/C controller condenser A/C pipeline A/C evaporator Air distribution Heater Other parts Right door harness

1

2

3

4

5

Позиция на иллюстрации	Заводской номер детали		Название детали
1	LF479Q1-1701015A		Transmission shell
2	Q72316		Gasket
3	LF479Q1-1701029A		Hex bolt plug
4	LF479Q1-2303313A		Spring washer for hole
5	LF479Q1-2303314B		Differential T seal
6	LF479Q1-1701141A		Spring circlip for shaft

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
