Каталог запасных частей к технике: Lifan LF-7130A1 Breez 1,3. Front brake
1-1
1-1
1-1
1-1
1-1-1
1-1-1
1-1-2
1-1-2
1-1-3
1-1-3
1-1-4
1-1-4
1-1-5
1-1-5
1-1-5
1-1-5
1-1-6
1-1-6
1-1-7
1-1-7
1-1-7
1-1-7
1-2
1-2
1-2
1-3
1-3
1-3
1-4
1-4
1-4
1-4
1-4
1-4
1-5
1-5
1-5
1-6
1-6
1-7
1-7
1-8
1-8
1-8
1-8
1-8
1-9
1-9
1-10
1-10
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | L3501100 | Left front brake with knuckle assy | |
| 1 | LAL3501100 | Left front brake with knuckle assy | |
| 1 | L3501200 | Right front brake with knuckle assy | |
| 1 | LAL3501200 | Right front brake with knuckle assy | |
| 1-1 | L3501110 | Left front brake caliper assy | |
| 1-1 | LAL3501110 | Left front brake caliper assy | |
| 1-1 | L3501210 | Right front brake caliper assy | |
| 1-1 | LAL3501210 | Right front brake caliper assy | |
| 1-1-1 | L3501124 | Bolt | |
| 1-1-1 | LAL3501124 | Bolt | |
| 1-1-2 | L3501122 | Axle pin | |
| 1-1-2 | LAL3501122 | Axle pin | |
| 1-1-3 | L3501111 | Venting screw | |
| 1-1-3 | LAL3501111 | Venting screw | |
| 1-1-4 | L3501112 | Venting screw cap | |
| 1-1-4 | LAL3501112 | Venting screw cap | |
| 1-1-5 | L3501120 | Left front brake caliper | |
| 1-1-5 | LAL3501120 | Left front brake caliper | |
| 1-1-5 | L3501220 | Right front brake caliper | |
| 1-1-5 | LAL3501220 | Right front brake caliper | |
| 1-1-6 | L3501123 | Axle pin sleeve | |
| 1-1-6 | LAL3501123 | Axle pin sleeve | |
| 1-1-7 | LAL3501121 | Caliper bracket left | |
| 1-1-7 | L3501121 | Caliper bracket left | |
| 1-1-7 | LAL3501221 | Caliper bracket right | |
| 1-1-7 | L3501221 | Caliper bracket right | |
| 1-2 | L3001104 | Circlip | |
| 1-2 | LAL3001104 | Circlip | |
| 1-2 | L3001104B1 | Circlip | |
| 1-3 | L3001103 | Front hub bearing | |
| 1-3 | LAL3001103 | Front hub bearing | |
| 1-3 | L3001103B1 | Front hub bearing | |
| 1-4 | L3001101 | Left knuckle | |
| 1-4 | LAL3001101 | Left knuckle | |
| 1-4 | L3001101B1 | Left knuckle | |
| 1-4 | L3001201 | Right knuckle | |
| 1-4 | LAL3001201 | Right knuckle | |
| 1-4 | L3001201B1 | Right knuckle | |
| 1-5 | L3001102 | Front hub | |
| 1-5 | LAL3001102 | Front hub | |
| 1-5 | L3001102B1 | Front hub | |
| 1-6 | L3501101 | Brake disc | |
| 1-6 | LAL3501101 | Brake disc | |
| 1-7 | L3501105 | Screw | |
| 1-7 | LAL3501105 | Screw | |
| 1-8 | SL35002 | Brake lining suite (4 pcs | |
| 1-8 | SL35003 | Brake lining suite (4 pcs | |
| 1-8 | SLAL35002 | Brake lining suite (4 pcs | |
| 1-8 | SL35001 | Brake lining suite (4 pcs | |
| 1-8 | SL35005 | Brake lining suite (4 pcs | |
| 1-9 | L3501103 | Caliper bolt | |
| 1-9 | LAL3501103 | Caliper bolt | |
| 1-10 | L3501104 | Washer | |
| 1-10 | LAL3501104 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
