Каталог запасных частей к технике: Lifan LF-7130A1 Breez 1,3. Dashboard trims
1
1
1
1
1
1
1-1
1-2
1-2
1-3
1-3
1-4
1-4
2
2
3
3
4
5
5
5
5
6
6
6
7
7
7
8
8
9
9
10
10
11
11
11
12
13
14
15
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | LAX5306000B02 | Dashboard | |
| 1 | LAX5306000B98 | Dashboard | |
| 1 | LAX5306000B99 | Dashboard | |
| 1 | LAX5306000A2B02 | Dashboard | |
| 1 | LAX5306000A2B98 | Dashboard | |
| 1 | LAX5306000A2B99 | Dashboard | |
| 1-1 | LAX8117150 | Air passage | |
| 1-2 | LAX5306310B04 | Air conditioner left nozzle | |
| 1-2 | LAX5306310B02 | Air conditioner left nozzle | |
| 1-3 | LAX5306330B04 | Air conditioner center nozzle | |
| 1-3 | LAX5306330B02 | Air conditioner center nozzle | |
| 1-4 | LAX5306320B04 | Air conditioner right nozzle | |
| 1-4 | LAX5306320B02 | Air conditioner right nozzle | |
| 2 | LAX5306022B04 | Instrument cluster cover, upper | |
| 2 | LAX5306022B02 | Instrument cluster cover, upper | |
| 3 | LAX5306105B04 | Passenger airbag cover | |
| 3 | LAX5306105B02 | Passenger airbag cover | |
| 4 | LAX5305304 | Dashboard trim clip | |
| 5 | LAX5306104B02 | Dashboard trim | |
| 5 | LAX5306104C02 | Dashboard trim | |
| 5 | LAX5306104B1B02 | Dashboard trim | |
| 5 | LAX5306104B1C02 | Dashboard trim | |
| 6 | Q2734816 | Philips self-tapping screw | |
| 7 | LAX5306601 | Instrument molding | |
| 7 | LAX5306601C02 | Instrument molding | |
| 7 | LAX5306601B03 | Instrument molding | |
| 8 | LAX5306701B04 | Steering pillar shield upper | |
| 8 | LAX5306701B02 | Steering pillar shield upper | |
| 9 | LAX5306702B04 | Steering pillar shield lower | |
| 9 | LAX5306702B02 | Steering pillar shield lower | |
| 10 | LAX5306023B04 | Instrument cluster cover, lower | |
| 10 | LAX5306023B02 | Instrument cluster cover, lower | |
| 11 | LAX5306019B02 | Left lower panel, dashboard | |
| 11 | LAX5306019B03 | Left lower panel, dashboard | |
| 11 | LAX5306019B05 | Left lower panel, dashboard | |
| 12 | 305B-0630T1F30 | Screw | |
| 13 | Q2734216 | Philips self-tapping screw | |
| 14 | LAL5531251 | Dashboard noise insulater, upper | |
| 15 | LAL5531252 | Dashboard noise insulater, lower |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
