Каталог запасных частей к технике: Great Wall GW-Sailor. SIDE WALL FRAME SHIELD ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
1
1
2
2
2
2
3
3
3
3
4
4
5
5
5
5
6
6
Позиция на иллюстрации Заводской номер детали Название детали
1 5402112-B00-0308 UPPER TRIM PANEL, RIGHT A PILLAR (MILK YELLOW)
1 5402111-B00-1214 UPPER TRIM PANEL, LEFT A PILLAR (06 GRAY)
1 5402112-B00-1214 UPPER TRIM PANEL, RIGHT A PILLAR (06 GRAY)
1 5402111-B00-0308 UPPER TRIM PANEL, LEFT A PILLAR (MILK YELLOW)
2 5402121-B00-0308 LOWER TRIM PANEL, LEFT A PILLAR (MILK YELLOW)
2 5402122-B00-0308 LOWER TRIM PANEL, RIGHT A PILLAR (MILK YELLOW)
2 5402121-B00-1214 LOWER TRIM PANEL, LEFT A PILLAR (06GRAY)
2 5402122-B00-1214 LOWER TRIM PANEL, RIGHT A PILLAR (06 GRAY)
3 5402211-B00-1214 LOWER TRIM PANEL, LEFT B PILLAR (06GRAY)
3 5402212-B00-1214 LOWER TRIM PANEL, RIGHT B PILLAR (06 GRAY)
3 5402212-B00-0308 LOWER TRIM PANEL, RIGHT B PILLAR (MILK YELLOW)
3 5402211-B00-0308 LOWER TRIM PANEL, LEFT B PILLAR (MILK YELLOW)
4 5402201-B00-0308 UPPER TRIM PANEL, B PILLAR (MILK YELLOW)
4 5402201-B00-1214 UPPER TRIM PANEL, B PILLAR (06 GRAY)
5 5402301-B00-0308 TRIM PANEL, LEFT C PILLAR (MILK YELLOW)
5 5402302-B00-0308 TRIM PANEL, RIGHT C PILLAR (MILK YELLOW)
5 5402301-B00-1214 TRIM PANEL, LEFT C PILLAR (06 GRAY)
5 5402302-B00-1214 TRIM PANEL, RIGHT C PILLAR (06 GRAY)
6 5602011-B00-0308 TRIM PANEL, CROSS MEMBER, REAR WALL (MILK YELLOW)
6 5602011-B00-1214 TRIM PANEL, CROSS MEMBER, REAR WALL (06 GRAY)
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
