Каталог запасных частей к технике: Great Wall GW-Sailor. REAR FLOOR ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
3
4
5
6
6
7
7
8
8
9
10
11
12
13
14
14
15
16
16
17
18
19
20
Позиция на иллюстрации Заводской номер детали Название детали
1 5120011-B00 FLOOR RUBBER PLUG
2 5130402-B00 MOUNTING BRACKET NO.4, BODY
3 5130403-B00 TRIANGLE REINFORCEMENT PLATE, LH
3 5130404-B00 TRIANGLE REINFORCEMENT PLATE, RH
4 5130410-B00 REAR INFORCEMENT CROSS MEMBER WITH NUT ASSEMBLY
5 5130401-B00 REINFORCEMENT PANEL (BACK STIFFENING BEAM)
6 5130021-B00 UPPER INNER PLATE, REAR LEFT PILLAR
6 5130022-B00 UPPER INNER PLATE, REAR RIGHT PILLAR
7 5130100-B00 LOWER INNER PLATE SUB-ASSEMBLY, REAR LEFT PILLAR
7 5130200-B00 LOWER INNER PLATE SUB-ASSEMBLY, REAR RIGHT PILLAR
8 5130017-B00 ROCKER TRIM PANEL, REAR, LH
8 5130018-B00 ROCKER TRIM PANEL, REAR, RH
9 5120012-B00 RUBBER PLUG, LOWER ROCKER
10 5130011-B00 LEFT PANEL , PASSENGER CAB
11 5130301-B00 FRONT PANEL, DRIVER CAB
12 5130023-B00 TRIANGLE PLATE
13 5130013-B00 CLAMP SEATREAR SEAT
14 5130012-B00 CAP SEATRIGHT PANEL
14 5130012-B50 CAP SEATRIGHT PANEL
15 5130019-B00 RIGHT SIDE FLOOR, REAR FLOOR
16 5130015-B00 FLOOR UNDER REAR SEAT
16 5130015-B00-C1 FLOOR UNDER REAR SEAT
17 5130016-B00 REINFORCEMENT PLATE, FLOOR UNDER REAR SEAT
18 5130302-B00 MAIN TRIANGLE IRON REINFORCEMENT PLATE
19 5130014-B00 CAP SEAT MIDDLE PANEL
20 5130024-B00 FLOOR UNDER KIT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
