1
1
1
2
3
3
3
3
4
4
5
6
7
Позиция на иллюстрации
Заводской номер детали
Название детали
1
2804105-B00
REAR BUMPER
1
2804105-B10-B1
REAR BUMPER
1
2804105-B11
REAR BUMPER
2
2804011-B00
ANTI-SKID PAD, REAR BUMPER
3
2804101-B00
LEFT BRACKET, REAR BUMPER
3
2804102-B00
RIGHT BRACKET, REAR BUMPER
3
2804101-B50
LEFT BRACKET, REAR BUMPER
3
2804102-B50
RIGHT BRACKET, REAR BUMPER
4
2804103-B00
REAR BUMPER BRACKET
4
2804103-B10
REAR BUMPER BRACKET
5
2804104-B00
REAR BUMPER CONNECTING BRACKET
6
2808011-B00
NUT PLATE, NUMBER PLATE LAMP
7
4135011-B00
RETROREFLECTOR
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
