1
1
2
2
3
3
4
5
5
6
6
6
7
Позиция на иллюстрации
Заводской номер детали
Название детали
1
1303011-B00
RADIATOR HOSE, UPPER
2
1301111-B00
RADIATOR CAP
3
1303012-B00
RADIATOR HOSE, LOWER
4
1301011-B00
RADIATOR RUBBER STRIP
5
1309010-B00
FAN SHROUD
6
1301100-B06
RADIATOR ASSEMBLY
6
1301100-L01
RADIATOR ASSEMBLY
6
1301100-B00
RADIATOR ASSEMBLY
7
1301011-B06
RADIATOR RUBBER STRIP
