1
1
1
1
1
2
2
3
3
4
5
6
7
8
9
9
9
10
11
Позиция на иллюстрации
Заводской номер детали
Название детали
5306260-B10-0111
5306260-B10-0111
VENTILATION GRILL KIT (WEAK DATE RED)
1
5306200-B00-0308
INSTRUMENT PANEL ASSEMBLY (MILK YELLOW)
1
5306200-B00-1214
INSTRUMENT PANEL ASSEMBLY (06 GRAY)
1
5306220-B00-0308
INSTRUMENT PANEL BODY ASSEMBLY (MILK YELLOW)
1
5306220-B00-1214
INSTRUMENT PANEL BODY ASSEMBLY (06GRAY)
1
5306200-B00-38*1C
INSTRUMENT PANEL ASSEMBLY (WEAK DATE RED)
2
5306202-B00-0308
UPPER AIR VENT, RH (MILK YELLOW)
2
5306202-B00-1214
UPPER AIR VENT, RH (06 GRAY)
3
5306011-B00
INSTRUMENT PANEL IRON COVER PLATE
3
5306011-B50
INSTRUMENT PANEL IRON COVER PLATE
4
5306209-B00
IRON CLIP NO.1, INSTRUMENT PANEL (Y CLAMP NUT A)
5
5306211-B00
IRON CLIP NO.2, INSTRUMENT PANEL
6
5306262-B00
VENTILATION GRILL
7
5306261-B00
VENTILATION GRILL SUPPORT
8
5306282-B00
GLOVE BOX LOCK
9
7901100-B00
RADIO AND CASSETTE PLAYER ASSEMBLY
9
7901100-B00-A2
RADIO AND CASSETTE PLAYER ASSEMBLY
9
7901100-B00-A1
RADIO AND CASSETTE PLAYER ASSEMBLY
10
8123014-B00
TUNNEL, RH
11
8123015-B00
TUNNEL, MIDDLE
