Позиция на иллюстрации
Заводской номер детали
Название детали
1
2300000-K01
FRONT DRIVE AXLE ASSEMBLY
2
2303320-K01
FRONT DRIVE AXLE HANGER ASSEMBLY, RH
3
2303310-K01
FRONT DRIVE AXLE HANGER ASSEMBLY, LH
4
2300015-K01
BUSHING GASKET
5
2300017-K01
BOLT, HANGING PLATE
6
2302100-K01
FRONT DIFFERENTIAL AND REDUCER ASSEMBLY
7
2303390-K01
CONSTANT VELOCITY DRIVE SHAFT ASSEMBLY
8
2303301-K01
SNAP SPRING
9
6006E-RSN
UNIVERSAL JOINT BEARING
10
2303380-K01
CONSTANT VELOCITY DRIVE SHAFT OIL SEAL
11
2303394-K01
BIG CLAMP, CONSTANT VELOCITY DRIVE SHAFT
12
2303392-K01
SLEEVE, CONSTANT VELOCITY DRIVE SHAFT
13
2303393-K01
BIG CLAMP, CONSTANT VELOCITY DRIVE SHAFT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
