1
2
3
4
5
6
7
8
9
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
1
3506010-L01
REAR BRAKE PIPE, RH, FROM MASTER CYLINDER TO COMBINATION VALVE
2
3506100-B06
REAR BRAKE OIL PIPE ASSEMBLY, LH
3
3506080-B00
LOAD-SENSING PROPORTIONING VALVE OIL PIPE ASSEMBLY
4
3506115-D01
REAR BRAKE HOSE
5
3506130-B06
REAR BRAKE OIL PIPE ASSEMBLY, RH
6
3506116-D01
REAR 3-WAY VALVE
7
3506070-B06
REAR BRAKE OIL PIPE ASSEMBLY
8
3506020-L01
FRONT BRAKE OIL PIPE ASSEMBLY, LH
9
3506070-K00
FRONT BRAKE HOSE
10
3506101-B06
FRONT 2-WAY VALVE
11
3506040-B06
FRONT BRAKE OIL PIPE ASSEMBLY, RH
12
3540200-L01
BRAKE MASTER CYLINDER AND VACUUM BOOSTER
