3502100-F00
3502200-F00
1
2
2
3
4
4
5
6
7
7
Позиция на иллюстрации
Заводской номер детали
Название детали
3502100-F00
3502100-F00
BRAKE ASSEMBLY, REARLH
3502200-F00
3502200-F00
REAR BRAKE ASSEMBLY, RH
1
3502190-F00
WHEEL CYLINDER ASSEMBLY
2
3502170-F00
LEFT SELF-ADJUSTING SCREW ASSEMBLY
2
3502180-F00
RIGHT SELF-ADJUSTING SCREW ASSEMBLY
3
3502011-F00
REAR BRAKE DRUM
4
3502101-F00
UPPER PULL SPRINGLH
4
3502102-F00
UPPER PULL SPRINGRH
5
3502111-F00
LOWER PULL SPRING
6
3502155-F00
BRAKE SHOE ASSEMBLY
7
3502130-F00
BOTTOM PLATE AND ANCHOR PIN ASSEMBLY, REARLH
7
3502140-F00
BOTTOM PLATE AND ANCHOR PIN ASSEMBLY, REARRH
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
