INSTRUMENT CONTROL CONSOLE (1)
INSTRUMENT CONTROL CONSOLE (2)
COMBINATION INSTRUMENT ASSEMBLY
WIRING HARNESS ARRANGEMENT (1)
WIRING HARNESS ARRANGEMENT (2)
WIRING HARNESS ARRANGEMENT (3)
WIRING HARNESS ARRANGEMENT (4)
TAIL DOOR (1)
TAIL DOOR (2)
TAIL DOOR (3)
TAIL DOOR (4)
TAIL DOOR UPPER FRAME ASSEMBLY
TAIL SPOILER
A/C (1) – CONDENSER AND RECEIVER DRYER
A/C (2) – COMPRESSOR ASSEMBLY
A/C (3) – EVAPORATOR AND BLOWER
A/C (4) – AIR TUNNEL
A/C (5) – HEAT RADIATOR ASSEMBLY
A/C (6) – CONTROLLER ASSEMBLY
VEHICLE LOGO
TOOLS ASSEMBLY
DECORATION RIBBON
1
1
1
1
1
2
3
4
5
6
7
8
9
10
10
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
7900030-F00
7900030-F00
XD LCD ASSEMBLY
1
3820100-F00
COMBINATION INSTRUMENT ASSEMBLY
1
3820100-F00-A1
COMBINATION INSTRUMENT ASSEMBLY
1
3820100-F00-A2
COMBINATION INSTRUMENT ASSEMBLY
1
3820100-F00-A3
COMBINATION INSTRUMENT ASSEMBLY
1
3820100-F00-A4
COMBINATION INSTRUMENT ASSEMBLY
2
4116040-F00
SWITCH ASSEMBLY, REAR FOG LAMP
3
4117030-F00
REGULATOR SWITCH ASSEMBLY, TAIL DOOR
4
4116030-F00
SWITCH ASSEMBLY, FOG LAMP
5
4117020-F00
SWITCH ASSEMBLY, WARNING LAMP
6
3603030-D07
DISPLAY SCREEN ASSEMBLY, BACK-UP RADAR
7
3748020-F00
MODE SWITCH ASSEMBLY
8
3748010-F00
DEFROST SWITCH ASSEMBLY
9
8112000-F02
ELECTRICALLY-CONTROLLED PANEL , AIR CONDITIONING
10
7901010-F00-A1
COMBINED VCD PLAYER ASSEMBLY
10
7900010-F00
COMBINED VCD PLAYER ASSEMBLY
10
7901010-F00
COMBINED VCD PLAYER ASSEMBLY
11
7900010-F00-B1
DIRECT SCREEN VCD PLAYER ASSEMBLY
12
7900020-F00
LCD DISPLAY SCREEN ASSEMBLY
