Каталог запасных частей к технике: Great Wall GW-Safe F1. FRONT BRAKE ASSEMBLY (F1)
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
14
15
15
16
17
17
18
19
20
20
21
22
23
24
25
26
27
28
29
29
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 3001107-К00 | FRONT WHEEL HUB COVER | |
| 2 | 3001104-К00 | SCREW, THRUST RING | |
| 3 | 3001103-К00 | NUT, THRUST RING STEEING KNUCKLE | |
| 4 | 3001102-К00 | NUT, STEERING KNUCKLE BEARING | |
| 5 | 32008Х | OUTER BEARING, STEERING KNUCKLE | |
| 6 | 3103104-К00 | WHEEL NUT | |
| 7 | 3103101-К00 | FRONT WHEEL HUB | |
| 8 | 3103103-К00 | FRONT WHEEL BOLT | |
| 9 | 3103102-К00 | FRONT BRAKE DISC | |
| 10 | ХАА32009Х | INNER BEARING STEERING KNUCKLE | |
| 11 | 3103110-К00 | OIL SEAL ASSEMBLY, FRONT WHEEL HUB | |
| 12 | 3001115-К00-В1 | BOLT, FRONT BRAKE HOUSING | |
| 13 | 3001113-К00-В1 | BRAKE HOUSINGFRONT, LH | |
| 13 | 3001114-К00-В1 | BRAKE HOUSINGFRONT, RH | |
| 14 | 3501103-К00 | SNAP SPRING NO.l, BRAKE PAD | |
| 15 | 3501104-К00 | SNAP SPRING NO.2, BRAKE PAD | |
| 16 | 3501120-К00 | BRAKE PAD ASSEMBLY | |
| 17 | 3501140-К00 | SILENT PAD KIT | |
| 18 | 3501108-К00 | PISTON DUST COVER | |
| 19 | 3501106-К00 | PISTON | |
| 20 | 3501111-К00 | DUST COVERDOWEL PIN/GUIDE PIN | |
| 21 | 3501107-К00 | RECTANGULAR SEALING RING | |
| 22 | 3501113-К00 | DOWEL PIN | |
| 23 | 3501115-К00 | BLEED SCREW | |
| 24 | 3501114-К00 | bleed screw cover | |
| 25 | 3001105-К00 | BOLT, BRAKE HOSE | |
| 26 | 3001106-К00 | COPPER WASHER | |
| 27 | 3501112-К00 | GUIDE PIN | |
| 28 | 3501104-К00 | SNAP SPRING NO.2, BRAKE PAD | |
| 29 | 3501101-К00 | FRONT CALIPERLH | |
| 29 | 3501102-К00 | FRONT CALIPERRH |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
