Каталог запасных частей к технике: Great Wall GW-Hower. Коробка переключения передач 4/2
Q40308
Q40308
1
2
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
30
31
32
33
34
34
35
36
37
38
39
40
300
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| Q40308 | Q40308 | WASHER 8 | |
| 1 | 1602001-K00 | CLUTCH HOUSING | |
| 2 | 1701001-K00 | BEARING BOX | |
| 3 | 1703024-K00 | CHOULDERED LOCK BOLT | |
| 4 | 1703023-K00 | CYLINDRICAL COMPRESSION SPRING | |
| 5 | 1703022-K00 | SPRING PIN | |
| 6 | 1703001-K00 | GEARBOX | |
| 7 | 1703042-K00 | BUSH | |
| 8 | 1703032-K00 | REVERSE LAMP SWITCH BRACKET | |
| 9 | 1703040-K00 | REAR HOUSING ASSEMBLY | |
| 10 | 1703013-K00 | SELECT AND SHIFT SEATING | |
| 11 | 1703016-K00 | ELASTIC CILINDRICAL PIN | |
| 12 | 1704003-K00 | HEXAGON BOLT ASSEMBLY | |
| 13 | 1703100-K00 | Рычаг переключения передач в сборе | |
| 14 | 1703011-K00 | GEAR SHIFT LEVER | |
| 15 | 1704003-K00 | HEXAGON BOLT ASSEMBLY | |
| 16 | 1703043-K00 | HEXAGON BOLT ASSEMBLY | |
| 17 | 1802323-K00 | Сальник вторичного вала КПП 39,6x52x10 | |
| 18 | 1802327-K00 | DUSTPROOF SEAL COVER | |
| 19 | 1703039-K00 | WIRE CLIP | |
| 20 | 1802337-K00 | HEXAGON BOLT ASSEMBLY | |
| 21 | 1802336-K00 | ODOMETER SEATING LOCK PLATE | |
| 22 | 1703050-K00 | ODOMETER DRIVEN GEAR ASSEMBLY | |
| 23 | 1703028-K00 | SHOULDERED LOCK SCREW PLUG | |
| 24 | 1703021-K00 | RETAINER SPING PIN | |
| 25 | 1704100-K00 | MAIN CONTROL LEVER ASSEMBLY | |
| 26 | 1704007-K00 | HEXAGON SET BOLT | |
| 27 | 1704006-K00 | HEXAGON BOLT ASSEMBLY | |
| 28 | 1704005-K00 | HEXAGON SET BOLT | |
| 30 | 1704141-K00 | RUBBER COVER | |
| 31 | 1704144-K00 | PIN | |
| 32 | 1704143-K00 | BALL JOINT | |
| 33 | 1704142-K00 | BALL JOINT SEAT | |
| 34 | 1704145-K00 | GASKET | |
| 35 | 1704146-K00 | MASTER LEVER STOP PLATE | |
| 36 | 1704321-K00 | BALL JOINT PROTECTIVE COVER | |
| 37 | 1704147-K00 | REVERSE LOCK BOLT | |
| 38 | 1704000-K00A1 | CONTROLLER COVER ASSEMBLY | |
| 39 | 1704310-K00 | REVERSE LOCK ASSEMBLY | |
| 40 | 1702079-K00 | NUT | |
| 300 | 1701000-K00 | Коробка передач в сборе 4/2 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
