Каталог запасных частей к технике: Great Wall GW-Deer. RIGHT FRONT DOOR ASSEMBLY
1
1
2
2
3
4
4
5
6
7
7
8
8
8
8
8
8
8
8
8
8
9
10
10
11
12
12
13
14
15
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6107302-D04 | FRONT DOOR GLASS RUN CHANNEL, RH | |
| 1 | 6107302-D01 | FRONT DOOR GLASS RUN CHANNEL, RH | |
| 2 | 6103012-D01 | FRONT DOOR GLASS, RH | |
| 2 | 6103012-D04 | FRONT DOOR GLASS, RH | |
| 3 | 6101011-D01 | DOOR DAMPING RUBBER BLOCK | |
| 4 | 6107502-D01 | FRONT DOOR EXTERIOR WEATHERSTRIP, RH | |
| 4 | 6107502-D04 | FRONT DOOR EXTERIOR WEATHERSTRIP, RH | |
| 5 | 6107503-D01 | CLIP, EXTERIOR WEATHESTRIP | |
| 6 | 6101600-D01 | REAR SECTION, FRONT DOOR LOWER GLASS RUN RAIL, RH | |
| 7 | 6101200-D01 | FRONT DOOR ASSEMBLY, RH | |
| 7 | 6101200-D06 | FRONT DOOR ASSEMBLY, RH | |
| 8 | 8202102-D07-C1 | EXTERIOR REAR-VIEW MIRRORLH | |
| 8 | 8202102-D62 | REARVIEW MIRROR, RH | |
| 8 | 8202102-D22-D1 | REARVIEW MIRROR, RH | |
| 8 | 8202102-D22-C1 | REARVIEW MIRROR, RH | |
| 8 | 8202102-D22-B1 | REARVIEW MIRROR, RH | |
| 8 | 8202102-D22 | REARVIEW MIRROR, RH | |
| 8 | 8202102-D07-B1 | EXTERIOR REAR-VIEW MIRRORLH | |
| 8 | 8202102-D07 | EXTERIOR REAR-VIEW MIRRORLH | |
| 8 | 8202102-D01-B1 | REARVIEW MIRROR, RH | |
| 8 | 8202102-D01 | REARVIEW MIRROR, RH | |
| 9 | 8202011-D01 | CLIP, TRIM PANEL, DOOR TRIANGULAR WINDOW | |
| 10 | 8202202-D01-0314 | TRIANGLE PLATE, EXTERIOR REAR VIEW MIRROR, RH | |
| 10 | 8202202-D01-0110 | TRIANGLE PLATE, EXTERIOR REAR VIEW MIRROR, RH | |
| 11 | 6101500-D01 | FRONT SECTION ASSEMBLY, LOWER GLASS RUN RAIL, RH | |
| 12 | 6107202-D01 | FRONT DOOR SEALING STRIPS, RH | |
| 12 | 6107202-D04 | FRONT DOOR SEALING STRIPS, RH | |
| 13 | 6101320-D06 | front door glass run rail REAR SEGMENT, LH | |
| 14 | 6101340-D06 | FRONT DOOR GLASS RUN RAIL REAR SEGMENT, RH | |
| 15 | 6109100-D01 | FRONT DOOR CHECK STOP ASSEMBLY |
