5401120-D01
1
2
3
4
5
7
9
10
11
11
12
12
Позиция на иллюстрации
Заводской номер детали
Название детали
5401120-D01
5401120-D01
A PILLAR ASSEMBLY, RH
1
5401112-D01
front roof rail, rh
2
5401460-D01
OUTER PANEL, RIGHT A PILLAR
3
5401320-D01
UPPER REINFORCEMENT PANEL, A PILLAR, RH
4
5401114-D01
UPPER INNER panel, a pillarrh
5
5401116-D01
UPPER REINFORCEMENT PANEL , A PILLAR, RH
7
5401440-D01
LOWER INNER PANEL, A PILLARRH
9
5401420-D01
lower reinforcement panel ASSEMBLY, A PILLAR, RH
10
5301031-D22
A PILLAR RUBBER PLUG
11
5402012-D01-0310
UPPER TRIM PANEL, RIGHT A PILLAR
11
5402012-D01-0110
UPPER TRIM PANEL, RIGHT A PILLAR
12
5402014-D01-0314
LOWER TRIM PANEL, RIGHT A PILLAR
12
5402014-D01-0110
LOWER TRIM PANEL, RIGHT A PILLAR
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
