Каталог запасных частей к технике: Great Wall GW-Deer. PARKING BRAKE CONTROLLER ASSEMBLY
1
2
2
2
3
3
3
4
5
6
6
6
6
6
6
6
6
6
6
7
7
7
7
7
7
7
7
7
7
8
9
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4134024-D01 | PARKING BRAKE LAMP SWTICH | |
| 2 | 3508110-D01 | PARKING BRAKE HANDLE ASSEMBLY | |
| 2 | 3508110-D22-1208 | PARKING BRAKE HANDLE ASSEMBLY | |
| 2 | 3508110-D22-0803 | PARKING BRAKE HANDLE ASSEMBLY | |
| 3 | 3508120-D01 | FRONT CABLE ASSEMBLY, PARKING BRAKE | |
| 3 | 3508120-D07 | FRONT CABLE ASSEMBLY, PARKING BRAKE | |
| 3 | 3508120-D08 | FRONT CABLE ASSEMBLY, PARKING BRAKE | |
| 4 | 3508130-D01 | PARKING BRAKE LEVER ASSEMBLY | |
| 5 | 3508101-D01 | GUIDE BRACKET, PARKING BRAKE CABLE | |
| 6 | 3502300-D04 | PARKING BRAKE CABLE ASSEMBLY, LH | |
| 6 | 3502300-D06 | PARKING BRAKE CABLE ASSEMBLY, LH | |
| 6 | 3502300-D05 | PARKING BRAKE CABLE ASSEMBLY, LH | |
| 6 | 3502300-D03 | PARKING BRAKE CABLE ASSEMBLY, LH | |
| 6 | 3502300-D08-B1 | PARKING BRAKE CABLE ASSEMBLY, LH | |
| 6 | 3502300-D02-B1 | PARKING BRAKE CABLE ASSEMBLY, LH | |
| 6 | 3502300-D02 | PARKING BRAKE CABLE ASSEMBLY, LH | |
| 6 | 3502300-D01-B1 | PARKING BRAKE CABLE ASSEMBLY, LH | |
| 6 | 3502300-D01 | PARKING BRAKE CABLE ASSEMBLY, LH | |
| 6 | 3502300-D07-B1 | PARKING BRAKE CABLE ASSEMBLY, LH | |
| 7 | 3502400-D02-B1 | PARKING BRAKE CABLE ASSEMBLY, RH | |
| 7 | 3502400-D06 | PARKING BRAKE CABLE ASSEMBLY, RH | |
| 7 | 3502400-D05 | PARKING BRAKE CABLE ASSEMBLY, RH | |
| 7 | 3502400-D03 | PARKING BRAKE CABLE ASSEMBLY, RH | |
| 7 | 3502400-D04 | PARKING BRAKE CABLE ASSEMBLY, RH | |
| 7 | 3502400-D08-B1 | PARKING BRAKE CABLE ASSEMBLY, RH | |
| 7 | 3502400-D07-B1 | PARKING BRAKE CABLE ASSEMBLY, RH | |
| 7 | 3502400-D02 | PARKING BRAKE CABLE ASSEMBLY, RH | |
| 7 | 3502400-D01-B1 | PARKING BRAKE CABLE ASSEMBLY, RH | |
| 7 | 3502400-D01 | PARKING BRAKE CABLE ASSEMBLY, RH | |
| 8 | 3502300-D07 | PARKING PARKING BRAKE CABLE ASSEMBLY | |
| 9 | 3508110-D07 | PARKING BRAKE HANDLE ASSEMBLY |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
