1
1
2
3
4
5
5
6
7
7
8
9
10
Позиция на иллюстрации
Заводской номер детали
Название детали
1
3808020-Е01
WATER TEMPERATURE SENSOR
1
3808020- E01-C1
WATER TEMPERATURE SENSOR
2
3791050-D01
REMOTE CONTROL MODULE ASSEMBLY
3
4131020-D01
DOOR LAMP SWITCH ASSEMBLY
4
3749021-D07
TEMPERATURE CONTROLLED SWITCH, RADIATOR FAN
5
3749021-D43
TEMPERATURE CONTROLLED SWITCH, RADIATOR FAN
5
3749021-D62
TEMPERATURE CONTROLLED SWITCH, RADIATOR FAN
6
3721010-D01
ELECTRIC HORN ASSEMBLY
7
4123010-D01-0310
CEILING LAMP ASSEMBLY
7
4123010-D01-0110
CEILING LAMP ASSEMBLY
8
4123011-D01
CEILING LAMP COVER
9
4123012-D01
ROOF LAMP BULB
10
3704011-D01
KEY FLAN
