Каталог запасных частей к технике: Great Wall GW-Deer. ELECTRICAL EQUIPMENT (1)
1
2
3
3
3
3
3
4
4
4
5
6
6
6
6
6
6
6
7
7
8
9
9
9
9
9
10
11
12
13
14
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 3735016-D01 | 3735016-D01 | COMPRESSOR RELAY | |
| 3735019-D01 | 3735019-D01 | FUEL PUMP RELAY | |
| 3735022-D01 | 3735022-D01 | ECU RELAY | |
| 3735014-D01 | 3735014-D01 | А/C RELAY | |
| 3735014-D07 | 3735014-D07 | A/C RELAY | |
| 7901030-D01 | 7901030-D01 | REAR SPEAKER ASSEMBLY | |
| 1 | 3722100-D01 | FUSE BLOCK ASSEMBLY, NO.l | |
| 2 | 3722100-D07 | FUSE BOX ASSEMBLY, NO.l | |
| 3 | 3735012-D01 | FLASHER RELAY | |
| 3 | 3735017-D01 | POWER WAVER REGULATOR RELAY | |
| 3 | 3735033-D22 | HIGH BEAM RELAY | |
| 3 | 3735018-D01 | TIME DELAY RELAY | |
| 3 | 3735011-D01 | LIGHT RELAY | |
| 4 | 3722201-D07-C1 | FUSE BLOCK COVER, NO.2 | |
| 4 | 3722201-D17 | FUSE BLOCK COVER, NO.2 | |
| 4 | 3722200-D01 | FUSE BLOCK COVER, NO.2 | |
| 5 | 3722202-D01 | FUSE BOX SEAT, NO.2 | |
| 6 | 3735027-D62 | TRIGGER RELAY | |
| 6 | 3735029-D62 | HORN RELAY | |
| 6 | 3735031-D17 | CHARGING RELAY | |
| 6 | 3735025-D07 | HIGH SPEED FAN RELAY | |
| 6 | 3735024-D07 | LOW SPEED FAN RELAY | |
| 6 | 3735023-D01 | ELECTROMAGNETIC FAN RELAY | |
| 6 | 3735015-D01 | FOG LAMP RELAY | |
| 7 | 3722200-D01 | FUSE BLOCK COVER, NO.2 | |
| 7 | 3722200-D07-C1 | FUSE BLOCK ASSEMBLY, NO.2 | |
| 8 | 3722300-D01 | FUSE BOX ASSEMBLY NO. 3 | |
| 9 | 3722015-D01 | FUSE 30A | |
| 9 | 3722014-D01 | FUSE 20A | |
| 9 | 3722013-D01 | FUSE 15A | |
| 9 | 3722012-D01 | FUSE 10A | |
| 9 | 3722011-D01 | FUSE 5A | |
| 10 | 3735012-D22 | WIPER INTERMITTENT RELAY | |
| 11 | 7901020-D01-B2 | FRONT SPEAKER ASSEMBLY, CD PLAYER | |
| 12 | 7901020-D07 | FRONT SPEAKER ASSEMBLY | |
| 13 | 7901050-D07-0314 | SPEAKER COVER ASSEMBLY, FRONT DOOR | |
| 14 | 3702010-D01 | REGULATOR ASSEMBLY, GENERATOR |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
